AddOn Networks ADD-SC-LC-26M9SMFP InfiniBand/fibre optic cable 26 m OFNP Yellow

Roll over image to zoom inClick to Open expanded view

AddOn Networks ADD-SC-LC-26M9SMFP InfiniBand/fibre optic cable 26 m OFNP Yellow

Name: AddOn Networks ADD-SC-LC-26M9SMFP InfiniBand/fibre optic cable 26 m OFNP Yellow
Brand: AddOn Networks
SKU: ADD-SC-LC-26M9SMFP

SKU: ADD-SC-LC-26M9SMFP

Log In to View Pricing

ETA 2 days

AddOn Networks ADD-SC-LC-26M9SMFP, 26 m, OFNP, OS2, LC, SC

ETA 2 days

Add to compare

Product Properties

Manufacturer
AddOn Networks

Warranty
Limited Lifetime

SKU
ADD-SC-LC-26M9SMFP

Certificates

Certification
CE, ISO/IEC 11801, TIA/EIA-568-C.3, TIA-604-5 (FOCIS-5), TIA/EIA-568-C.1, GR-409-CORE, ICEA S-83-596

Compliance certificates
RoHS, Telecommunicatios Industry Association (TIA)

Features

Cable length
26 m

Cable shape
Round

Cable type
OFNP

Cladding diameter
125 µm

Compressive strength
10

Connector 1
LC

Connector 1 gender
Male

Connector 2
SC

Connector 2 gender
Male

Connector material
Ceramic

Connector polish type
UPC

Core diameter
9 µm

Data transfer rate
100 Gbit/s

Ethernet interface type
100 Gigabit Ethernet, Gigabit Ethernet

Export Control Classification Number (ECCN)
EAR99

Fiber mode structure
Single-mode

Fibre optic type
OS2

Full duplex
Yes

Insertion loss
0.35 dB

Jacket material
Polyvinylidene fluoride (PVDF)

Plug and Play
Yes

Polarity
A/B

Product colour
Yellow

Return loss
30 dB

Wavelengths supported
1310,1550 nm

Logistics data

Country of origin
China

Harmonized System (HS) code
85447000, 8544.70.0000

Operational conditions

Operating temperature (T-T)
0 - 60 °C

Storage temperature (T-T)
-10 - 70 °C

Other features

UNSPSC-code
26121609

Packaging content

Quantity per pack
1 pc(s)

Sustainability

Doesn't contain
Halogen

Weight & dimensions

Cable diameter
1.6 mm

Description

AddOn Networks ADD-SC-LC-26M9SMFP. Cable length: 26 m, Cable type: OFNP, Fibre optic type: OS2, Connector 1: LC, Connector 2: SC, Core diameter: 9 µm, Full duplex

OFNP OS2
26 m
LC Male
SC Male
Connector polish type: UPC
Jacket material: Polyvinylidene fluoride (PVDF)
100 Gbit/s
Full duplex Single-mode
Yellow
