• Design

• Cable lock slot type
• Kensington

• Chassis type
• Rack-mounted chassis

• Number of 2.5" bays
• 4

• Number of 3.5" bays
• 5

• Number of 5.25" bays
• 1

• Placement supported
• Horizontal/Vertical

• Product colour
• Black

• Expansion slots

• PCI Express x1 (Gen 3.x) slots
• 2

• PCI Express x16 (Gen 3.x) slots
• 2

• PCI Express x4 (Gen 3.x) slots
• 2

• PCI Express x8 (Gen 3.x) slots
• 1

• Filters

• Machinecategory
• Workstation

• Graphics

• Discrete graphics card
• Yes

• Discrete graphics card memory
• 8 GB

• Discrete graphics card model
• NVIDIA Quadro RTX 4000

• Discrete graphics memory type
• GDDR6

• On-board graphics card
• No

• On-board graphics card model
• Not available

• Logistics data

• Harmonized System (HS) code
• 84715000

• Memory

• ECC
• Yes

• Internal memory type
• DDR4-SDRAM

• Memory channels
• Quad-channel

• Memory clock speed
• 2933 MHz

• Memory Installed
• 16 GB

• Memory layout (slots x size)
• 1 x 16 GB

• Memory Slot Support
• 512 GB

• Memory slots
• 8x DIMM

• Network

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet LAN
• Yes

• Ethernet LAN data rates
• 10,100,1000 Mbit/s

• Operational conditions

• Operating relative humidity (H-H)
• 5 - 85%

• Operating temperature (T-T)
• 10 - 35 °C

• Packaging content

• Display included
• No

• Performance

• Audio chip
• Realtek ALC671

• Audio system
• High Definition Audio

• BIOS type
• UEFI

• Motherboard chipset
• Intel® C422

• Motherboard form factor
• Extended ATX

• Password protection
• Yes

• Product type
• Workstation

• Trusted Platform Module (TPM)
• Yes

• Ports & interfaces

• Ethernet LAN (RJ-45) ports
• 1

• Headphone outputs
• 1

• Line-in
• Yes

• Line-out
• Yes

• Microphone in
• Yes

• SATA Ports
• 8

• Total number of SATA connectors
• 8

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 6

• Power

• Power supply
• 450 W

• Power supply input frequency
• 50/60 Hz

• Power supply input voltage
• 100 - 240 V

• Processor

• Maximum internal memory supported by processor
• 256 GB

• Maximum number of PCI Express lanes
• 48

• Memory clock speeds supported by processor
• 2933 MHz

• Memory types supported by processor
• DDR4-SDRAM

• Number of Cores
• 10

• Number of processors installed
• 1

• PCI Express slots version
• 3.0

• Processor
• i9-10900X

• Processor boost frequency
• 4.5 GHz

• Processor cache
• 19.25 MB

• Processor cache type
• Smart Cache

• Processor codename
• Cascade Lake

• Processor family
• Intel® Core™ i9 X-series

• Processor frequency
• 3.7 GHz

• Processor generation
• 10th gen Intel® Core™ i9

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor socket
• LGA 2066 (Socket R4)

• Processor threads
• 20

• Thermal Design Power (TDP)
• 165 W

• Tjunction
• 94 °C

• Processor special features

• CPU configuration (max)
• 1

• Embedded options available
• No

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Intel 64
• Yes

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Processor ARK ID
• 198019

• Scalability
• 1S

• Supported instruction sets
• SSE4.1, SSE4.2, AVX 2.0, AVX-512

• Thermal solution specification
• PCG 2017X

• Software

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 10 Pro

• Storage

• Number of SSDs installed
• 1

• Number of storage drives installed
• 1

• NVMe
• Yes

• Optical drive type
• DVD Super Multi

• SSD form factor
• M.2

• SSD interface
• NVMe

• Storage Capacity
• 256 GB

• Storage type
• SSD

• Total SSDs capacity
• 256 GB

• Sustainability

• Sustainability certificates
• RoHS, ENERGY STAR

• Weight & dimensions

• Depth
• 500 mm

• Height
• 433 mm

• Weight
• 18 kg

• Width
• 176 mm
