Equip USB-C to 2.5 Gigabit Ethernet Network (USB-C+A) Adapter

Roll over image to zoom inClick to Open expanded view

Equip USB-C to 2.5 Gigabit Ethernet Network (USB-C+A) Adapter

Name: Equip USB-C to 2.5 Gigabit Ethernet Network (USB-C+A) Adapter
Brand: LevelOne
SKU: 133495

SKU: 133495

Log In to View Pricing

ETA 7 days

Equip USB-C to 2.5 Gigabit Ethernet Network (USB-C+A) Adapter, Wired, USB Type-A/USB Type-C, Ethernet, 2500 Mbit/s, Grey

ETA 7 days

hypertec

Datasheets (Download)

Add to compare

Product Properties

Manufacturer
LevelOne

Warranty
2 Years

SKU
133495

EAN
4015867236635

Bullet points

Point
10/100/1000/2500 Mbps wire speed transmission and reception

Aluminum casing

Auto MDI-X: Supports patch and crossover cables, automatic detection and switching

Built-in Wake-on-LAN feature to startup computers remotely and standby.

Compatible with Windows, MacOS, Linux, Android and iOS

Full duplex / half-duplex data flow control - auto-negotiation

RJ45 Ethernet socket with LED function display

RJ45 female x 1

Supports USB A+C ports

USB-C Male x 1 (Thunderbolt 3/4 Compatible)

Design

Component for
PC/Laptop

Country of origin
China

Internal
No

LED indicators
Yes

Product colour
Grey

Logistics data

Harmonized System (HS) code
8517620090

Master (outer) case gross weight
5.8 kg

Master (outer) case height
250 mm

Master (outer) case length
290 mm

Master (outer) case width
440 mm

Products per master (outer) case
100 pc(s)

Network

Auto MDIX IEEE
Yes

Ethernet interface type
2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet

Ethernet LAN
Yes

Ethernet LAN data rates
10,100,1000,2500 Mbit/s

Full duplex
Yes

Maximum data transfer rate
2500 Mbit/s

Networking standards
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u

VLAN tagging
Yes

Wake-on-LAN ready
Yes

Other features

Cable length
0.15 m

Housing material
Aluminium

Packaging data

Package depth
22 mm

Package height
158 mm

Package weight
52 g

Package width
85 mm

Ports & interfaces

Connectivity technology
Wired

Ethernet LAN (RJ-45) ports
1

Host interface
USB Type-A/USB Type-C

Interface
Ethernet

Sustainability

Sustainability compliance
Yes

System requirements

Linux operating systems supported
Yes

Other operating systems supported
Android, iOS

Technical details

Compliance certificates
CE, RoHS

Weight & dimensions

Depth
16.5 mm

Height
60 mm

Weight
32 g

Width
23.4 mm

Description

Equip USB-C to 2.5 Gigabit Ethernet Network (USB-C+A) Adapter. Connectivity technology: Wired, Host interface: USB Type-A/USB Type-C, Interface: Ethernet. Maximum data transfer rate: 2500 Mbit/s. Product colour: Grey

Wired
USB Type-A/USB Type-C Ethernet
2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet 2500 Mbit/s
Component for: PC/Laptop
USB-C Male x 1 (Thunderbolt 3/4 Compatible)
RJ45 Female x 1
Supports USB A+C ports
10/100/1000/2500 Mbps wire speed transmission and reception
RJ45 Ethernet socket with LED function display
Built-in Wake-on-LAN feature to startup computers remotely and standby.
Full duplex / half-duplex data flow control - auto-negotiation
Auto MDI-X: Supports patch and crossover cables, automatic detection and switching
Compatible with Windows, MacOS, Linux, Android and iOS
Aluminum casing
