• Bullet points

• Point
• 16GB (2933MHz) DDR4-SDRAM (2 x 8) & 512GB SSD
  Intel Core i7-10700 (16MB Cache, 2.9GHz)
  NVIDIA Quadro P1000 (4GB GDDR4)
  Windows 10 Pro 64-bit

• Design

• Cable lock slot
• Yes

• Chassis type
• SFF

• Intel® vPro™ Platform Eligibility
• Yes

• Product colour
• Black

• Filters

• Machinecategory
• Workstation

• Graphics

• Discrete graphics card
• Yes

• Discrete graphics card memory
• 4 GB

• Discrete graphics card model
• NVIDIA® Quadro® P1000

• Discrete graphics memory type
• GDDR4

• Maximum on-board graphics card memory
• 64 GB

• Number of displays supported (on-board graphics)
• 3

• On-board GPU manufacturer
• Intel

• On-board graphics card
• Yes

• On-board graphics card base frequency
• 350 MHz

• On-board graphics card DirectX version
• 12.0

• On-board graphics card dynamic frequency (max)
• 1200 MHz

• On-board graphics card ID
• 0x9BC5

• On-board graphics card model
• Intel® UHD Graphics 630

• On-board graphics card OpenGL version
• 4.5

• Logistics data

• Harmonized System (HS) code
• 84715000

• Memory

• Internal memory type
• DDR4-SDRAM

• Memory clock speed
• 2933 MHz

• Memory Installed
• 16 GB

• Memory layout (slots x size)
• 2 x 8 GB

• Memory Slot Support
• 128 GB

• Memory slots
• 4x DIMM

• Network

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet LAN
• Yes

• Ethernet LAN data rates
• 10,100,1000 Mbit/s

• Wi-Fi
• No

• Operational conditions

• Non-operating altitude
• 0 - 10668 m

• Non-operating vibration
• 2 G

• Operating altitude
• 0 - 3048 m

• Operating relative humidity (H-H)
• 20 - 85%

• Operating temperature (T-T)
• 10 - 35 °C

• Operating vibration
• 0.52 G

• Storage relative humidity (H-H)
• 5 - 95%

• Storage temperature (T-T)
• -40 - 65 °C

• Packaging content

• Cables included
• AC

• Display included
• No

• Keyboard included
• Yes

• Mouse included
• Yes

• Performance

• Audio chip
• Realtek ALC3246

• Audio system
• High Definition Audio

• Motherboard chipset
• Intel W480

• Password protection
• Yes

• Product type
• Workstation

• Trusted Platform Module (TPM)
• Yes

• Ports & interfaces

• Combo headphone/mic port
• Yes

• DisplayPort version
• 1.4

• DisplayPorts quantity
• 2

• DVI port
• No

• Ethernet LAN (RJ-45) ports
• 1

• Headphone outputs
• 1

• Line-out
• Yes

• Microphone in
• No

• Number of USB ports with PowerShare support
• 1

• PowerShare
• Yes

• PS/2 ports quantity
• 2

• USB 2.0 ports quantity
• 4

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 3

• USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
• 2

• USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
• 1

• Power

• Power supply input frequency
• 50/60 Hz

• Power supply input voltage
• 100 - 240 V

• Processor

• Maximum internal memory supported by processor
• 128 GB

• Maximum number of PCI Express lanes
• 16

• Memory bandwidth supported by processor (max)
• 45.8 GB/s

• Memory clock speeds supported by processor
• 2933 MHz

• Memory types supported by processor
• DDR4-SDRAM

• Number of Cores
• 8

• Number of processors installed
• 1

• PCI Express configurations
• 1x16, 2x8, 1x8+2x4

• PCI Express slots version
• 3.0

• Processor
• i7-10700

• Processor boost frequency
• 4.8 GHz

• Processor cache
• 16 MB

• Processor cache type
• Smart Cache

• Processor codename
• Comet Lake

• Processor family
• Intel® Core™ i7

• Processor frequency
• 2.9 GHz

• Processor generation
• 10th gen Intel® Core™ i7

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor socket
• LGA 1200 (Socket H5)

• Processor threads
• 16

• System bus rate
• 8 GT/s

• Thermal Design Power (TDP)
• 65 W

• Tjunction
• 100 °C

• Processor special features

• CPU configuration (max)
• 1

• Embedded options available
• No

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Idle States
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• Yes

• Intel Software Guard Extensions (Intel SGX)
• Yes

• Intel Stable Image Platform Program (SIPP)
• Yes

• Intel Trusted Execution Technology
• Yes

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Clear Video HD Technology (Intel® CVT HD)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• Yes

• Intel® InTru™ 3D Technology
• Yes

• Intel® OS Guard
• Yes

• Intel® Quick Sync Video Technology
• Yes

• Intel® Secure Key
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Processor ARK ID
• 199316

• Processor package size
• 37.5 x 37.5 mm

• Scalability
• 1S

• Supported instruction sets
• SSE4.1, SSE4.2, AVX 2.0

• Thermal Monitoring Technologies
• Yes

• Thermal solution specification
• PCG 2015C

• Software

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 10 Pro

• Operating system language
• Multilingual

• Trial software
• Microsoft Office

• Storage

• Number of SSDs installed
• 1

• Optical drive type
• DVD-RW

• SSD capacity
• 512 GB

• SSD form factor
• M.2

• SSD interface
• PCI Express

• Storage Capacity
• 512 GB

• Storage type
• SSD

• Total SSDs capacity
• 512 GB

• Weight & dimensions

• Depth
• 292.8 mm

• Height
• 290 mm

• Package depth
• 394 mm

• Package height
• 264 mm

• Package weight
• 8.67 kg

• Package width
• 487 mm

• Weight
• 5.59 kg

• Width
• 92.6 mm
