• Certificates

• Certification
• CECP, WEEE

• Design

• Cable lock slot
• Yes

• Cable lock slot type
• Kensington

• Chassis type
• mini PC

• Number of 2.5" bays
• 1

• Placement supported
• Horizontal/Vertical

• Product colour
• Black

• Volume
• 1.2 L

• Water cooling system
• No

• Filters

• Machinecategory
• Personal computer

• Graphics

• Discrete graphics card model
• Not available

• Graphics card Open GL support
• Yes

• Maximum on-board graphics card memory
• 1.74 GB

• Number of displays supported (on-board graphics)
• 3

• On-board graphics card
• Yes

• On-board graphics card base frequency
• 350 MHz

• On-board graphics card DirectX version
• 12.0

• On-board graphics card dynamic frequency (max)
• 1100 MHz

• On-board graphics card family
• Intel® HD Graphics

• On-board graphics card ID
• 1912

• On-board graphics card model
• Intel® HD Graphics 530

• On-board graphics card OpenGL version
• 4.4

• Memory

• Internal memory type
• DDR4-SDRAM

• Memory channels
• Dual-channel

• Memory clock speed
• 2133 MHz

• Memory Installed
• 8 GB

• Memory Slot Support
• 16 GB

• Memory slots
• 2x SO-DIMM

• Non-ECC
• Yes

• Network

• Bluetooth
• Yes

• Bluetooth version
• 4.1

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet LAN
• Yes

• Ethernet LAN data rates
• 10,100,1000 Mbit/s

• Top Wi-Fi standard
• Wi-Fi 5 (802.11ac)

• Wi-Fi
• Yes

• Wi-Fi standards
• Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)

• Operational conditions

• Non-operating altitude
• -15.2 - 10668 m

• Operating altitude
• -15.2 - 3048 m

• Operating relative humidity (H-H)
• 20 - 80%

• Operating temperature (T-T)
• 5 - 35 °C

• Storage relative humidity (H-H)
• 5 - 95%

• Storage temperature (T-T)
• -40 - 65 °C

• Other features

• Intel segment tagging
• Enterprise, Small Business

• Packaging content

• AC adapter included
• Yes

• Cables included
• AC

• Display included
• No

• Manual
• Yes

• Performance

• Audio system
• HD

• Motherboard chipset
• Intel® Q170

• Password protection
• Yes

• Password protection type
• BIOS

• Product type
• Mini PC

• Ports & interfaces

• Combo headphone/mic port
• Yes

• DC-in jack
• Yes

• DisplayPorts quantity
• 1

• DVI port
• No

• Ethernet LAN (RJ-45) ports
• 1

• HDMI ports
• 1

• Line-out
• Yes

• Microphone in
• No

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 6

• Power

• Power supply
• 65 W

• Power supply input frequency
• 50 - 60 Hz

• Power supply input voltage
• 100 - 240 V

• Processor

• Bus type
• DMI3

• ECC supported by processor
• No

• FSB Parity
• No

• Maximum internal memory supported by processor
• 64 GB

• Maximum number of PCI Express lanes
• 16

• Memory bandwidth supported by processor (max)
• 34.1 GB/s

• Memory clock speeds supported by processor
• 2133,1333,1600,1866 MHz

• Memory types supported by processor
• DDR3L-SDRAM, DDR4-SDRAM

• Memory voltage supported by processor
• 1.35 V

• Number of Cores
• 4

• Number of processors installed
• 1

• PCI Express configurations
• 1x16, 2x8, 1x8+2x4

• PCI Express slots version
• 3.0

• Processor
• i7-6700T

• Processor boost frequency
• 3.6 GHz

• Processor cache
• 8 MB

• Processor cache type
• Smart Cache

• Processor codename
• Skylake

• Processor family
• Intel® Core™ i7

• Processor frequency
• 2.8 GHz

• Processor generation
• 6th gen Intel® Core™ i7

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor series
• Intel Core i7-6700 Desktop series

• Processor socket
• LGA 1151 (Socket H4)

• Processor threads
• 8

• Stepping
• R0

• System bus rate
• 8 GT/s

• Tcase
• 66 °C

• Thermal Design Power (TDP)
• 35 W

• Processor special features

• Conflict-Free processor
• Yes

• CPU configuration (max)
• 1

• Embedded options available
• No

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Graphics & IMC lithography
• 14 nm

• Idle States
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• Yes

• Intel Demand Based Switching
• No

• Intel Dual Display Capable Technology
• No

• Intel Enhanced Halt State
• Yes

• Intel Fast Memory Access
• No

• Intel FDI Technology
• No

• Intel Flex Memory Access
• No

• Intel HD Graphics
• Yes

• Intel Identity Protection Technology version
• 1.00

• Intel Rapid Storage Technology
• No

• Intel Secure Key Technology version
• 1.00

• Intel Small Business Advantage (SBA) version
• 1.00

• Intel Software Guard Extensions (Intel SGX)
• Yes

• Intel Stable Image Platform Program (SIPP)
• Yes

• Intel Stable Image Platform Program (SIPP) version
• 1.00

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• Yes

• Intel TSX-NI version
• 1.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Anti-Theft Technology (Intel® AT)
• No

• Intel® Built-in Visuals Technology
• Yes

• Intel® Clear Video HD Technology (Intel® CVT HD)
• Yes

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• Yes

• Intel® Insider™
• Yes

• Intel® InTru™ 3D Technology
• Yes

• Intel® My WiFi Technology (Intel® MWT)
• No

• Intel® OS Guard
• Yes

• Intel® Quick Sync Video Technology
• Yes

• Intel® Secure Key
• Yes

• Intel® Small Business Advantage (Intel® SBA)
• Yes

• Intel® Smart Cache
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Intel® Unite™
• Yes

• Intel® Wireless Display (Intel® WiDi)
• Yes

• Processor ARK ID
• 88200

• Processor code
• SR2BU

• Processor package size
• 37.5 x 37.5 mm

• Scalability
• 1S

• Supported instruction sets
• SSE4.2, AVX 2.0, SSE4.1

• Thermal Monitoring Technologies
• Yes

• Thermal solution specification
• PCG 2015A

• Software

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 7 Professional

• Optional operating system supplied
• Windows 10 Pro

• Storage

• Card reader integrated
• No

• Number of SSDs installed
• 1

• Optical drive type
• No

• SSD capacity
• 128 GB

• Storage Capacity
• 128 GB

• Storage type
• SSD

• Sustainability

• Sustainability certificates
• RoHS, ENERGY STAR

• Weight & dimensions

• Depth
• 176 mm

• Height
• 182 mm

• Weight
• 1.28 kg

• Width
• 36 mm
