• Design

• Chassis type
• Tower

• Product colour
• Black

• Volume
• 33 L

• Filters

• Machinecategory
• Workstation

• Graphics

• Discrete graphics card
• Yes

• Discrete graphics card memory
• 8 GB

• Discrete graphics card model
• NVIDIA® Quadro® P4000

• Number of discrete graphics cards
• 1

• Memory

• ECC
• Yes

• Internal memory type
• DDR4-SDRAM

• Memory channels
• Quad-channel

• Memory clock speed
• 2666 MHz

• Memory Installed
• 16 GB

• Memory Slot Support
• 256 GB

• Memory slots
• 8x DIMM

• Network

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet LAN
• Yes

• Ethernet LAN data rates
• 10,100,1000 Mbit/s

• Operational conditions

• Operating relative humidity (H-H)
• 10 - 80%

• Operating temperature (T-T)
• 10 - 35 °C

• Storage relative humidity (H-H)
• 10 - 90%

• Storage temperature (T-T)
• -10 - 60 °C

• Other features

• Optical drives quantity
• 1

• Packaging content

• Display included
• No

• Keyboard included
• Yes

• Manual
• Yes

• Mouse included
• Yes

• Performance

• Motherboard chipset
• Intel® C422

• Password protection
• Yes

• Product type
• Workstation

• Ports & interfaces

• Combo headphone/mic port
• Yes

• DVI port
• No

• Ethernet LAN (RJ-45) ports
• 1

• Headphone outputs
• 1

• Line-in
• Yes

• Line-out
• Yes

• Microphone in
• Yes

• PS/2 ports quantity
• 2

• USB 2.0 ports quantity
• 2

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 8

• Power

• Power supply
• 690 W

• Power supply input frequency
• 50 - 60 Hz

• Power supply input voltage
• 100 - 240 V

• Processor

• Bus type
• QPI

• ECC supported by processor
• Yes

• Maximum internal memory supported by processor
• 512 GB

• Maximum number of PCI Express lanes
• 48

• Memory bandwidth supported by processor (max)
• 85.3 GB/s

• Memory clock speeds supported by processor
• 1600,1866,2133,2400,2666 MHz

• Memory types supported by processor
• DDR4-SDRAM

• Number of Cores
• 6

• Number of processors installed
• 1

• PCI Express configurations
• 1x16, 1x4, 1x8

• PCI Express slots version
• 3.0

• Processor
• W-2133

• Processor boost frequency
• 3.9 GHz

• Processor cache
• 8.25 MB

• Processor codename
• Skylake

• Processor family
• Intel® Xeon®

• Processor frequency
• 3.6 GHz

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor socket
• LGA 2066 (Socket R4)

• Processor threads
• 12

• Stepping
• U0

• Tcase
• 65 °C

• Thermal Design Power (TDP)
• 140 W

• Processor special features

• Conflict-Free processor
• Yes

• CPU configuration (max)
• 1

• Embedded options available
• No

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Idle States
• Yes

• Intel 64
• Yes

• Intel Demand Based Switching
• Yes

• Intel Enhanced Halt State
• Yes

• Intel Flex Memory Access
• No

• Intel Identity Protection Technology version
• 1.00

• Intel Secure Key Technology version
• 1.00

• Intel Software Guard Extensions (Intel SGX)
• No

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• Yes

• Intel TSX-NI version
• 1.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• Yes

• Intel® OS Guard
• Yes

• Intel® Secure Key
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Physical Address Extension (PAE)
• 46 bit
  Yes

• Processor ARK ID
• 125040

• Processor code
• SR3LL

• Processor package size
• 45 x 52.5 mm

• Scalability
• 1S

• Supported instruction sets
• AVX, AVX 2.0, AVX-512, SSE4.2

• Thermal Monitoring Technologies
• Yes

• Software

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 10 Pro for Workstations

• Recovery operating system
• Windows 7 Professional

• Storage

• Card reader integrated
• Yes

• Number of SSDs installed
• 1

• Number of storage drives installed
• 1

• Optical drive type
• DVD±RW

• SSD capacity
• 512 GB

• Storage Capacity
• 512 GB

• Storage type
• SSD

• Sustainability

• Sustainability certificates
• RoHS, EPEAT Gold, ENERGY STAR

• Weight & dimensions

• Depth
• 460 mm

• Height
• 440 mm

• Weight
• 24 kg

• Width
• 165 mm
