LevelOne POI-3010 PoE adapter Fast Ethernet, Gigabit Ethernet 52 V

Roll over image to zoom inClick to Open expanded view

LevelOne POI-3010 PoE adapter Fast Ethernet, Gigabit Ethernet 52 V

Name: LevelOne POI-3010 PoE adapter Fast Ethernet, Gigabit Ethernet 52 V
Brand: LevelOne
SKU: POI-3010

SKU: POI-3010

Log In to View Pricing

ETA 7 days

LevelOne POI-3010, Fast Ethernet, Gigabit Ethernet, 10,100,1000 Mbit/s, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, Black, 100 m, PoE, Power

ETA 7 days

hypertec

Datasheets (Download)

Add to compare

Product Properties

Manufacturer
LevelOne

Warranty
1 Year

SKU
POI-3010

EAN
4015867221815

Bullet points

Point
10/100/1000Mbps wire speed transmission and reception

Auto-detection and protection of non-standard PoE devices

IEEE 802.3af/at PoE PSE with 30W power budget

Unique interlocking feature for easy installation

Certificates

Certification
FCC Part 15, CE

Compliance certificates
RoHS

Features

LED indicators
PoE, Power

Maximum operating distance
100 m

Pin assignment & polarity
1/2 (+), 3/6 (-)

Plug and Play
Yes

Product colour
Black

Surge protection
Yes

Wall mountable
Yes

Logistics data

Harmonized System (HS) code
85044095

Network

Ethernet interface type
Fast Ethernet, Gigabit Ethernet

Ethernet LAN data rates
10,100,1000 Mbit/s

Networking standards
IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u

Power over Ethernet (PoE)
Yes

Operational conditions

Operating relative humidity (H-H)
5 - 95%

Operating temperature (T-T)
0 - 45 °C

Storage relative humidity (H-H)
5 - 95%

Storage temperature (T-T)
0 - 70 °C

Packaging content

Number of products included
1 pc(s)

Power cord included
Yes

Quick installation guide
Yes

Packaging data

Package depth
125 mm

Package height
55 mm

Package type
Box

Package weight
400 g

Package width
210 mm

Ports & interfaces

Ethernet LAN (RJ-45) ports
2

Power

AC adapter frequency
50/60 Hz

AC adapter input voltage
100 - 240 V

Input current
0.8 A

Output current
0.6 A

Power consumption (max)
30 W

Power over Ethernet (PoE) power per port
30 W

Power over Ethernet (PoE) voltage
52 V

Weight & dimensions

Depth
51 mm

Height
38 mm

Weight
350 g

Width
143 mm

Description

LevelOne POI-3010. Ethernet interface type: Fast Ethernet, Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u. Product colour: Black, Maximum operating distance: 100 m, LED indicators: PoE, Power. Power over Ethernet (PoE) voltage: 52 V, AC adapter input voltage: 100 - 240 V, AC adapter frequency: 50/60 Hz. Compliance certificates: RoHS, Certification: FCC Part 15, CE. Width: 143 mm, Depth: 51 mm, Height: 38 mm

10,100,1000 Mbit/s 100 m
Power over Ethernet (PoE) IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Black
IEEE 802.3af/at PoE PSE with 30W power budget
Auto-detection and protection of non-standard PoE devices
Unique interlocking feature for easy installation
10/100/1000Mbps wire speed transmission and reception
