Neomounts WL95-800BL1 Videowall wall mount 42-70" - pop-out - max 35 kg

Roll over image to zoom inClick to Open expanded view

Neomounts WL95-800BL1 Videowall wall mount 42-70" - pop-out - max 35 kg

Name: Neomounts WL95-800BL1 Videowall wall mount 42-70" - pop-out - max 35 kg
Brand: Neomounts
SKU: WL95-800BL1

SKU: WL95-800BL1

Log In to View Pricing

ETA 6 days

Neomounts WL95-800BL1 Videowall wall mount 42-70" - pop-out - max 35 kg, 35 kg, 106.7 cm (42"), 177.8 cm (70"), 200 x 200 mm, 600 x 400 mm, 0 - 13 mm

ETA 6 days

hypertec

Safety information (Download)

Product manual (Download)

WL95-800BL1_Greensheet_EN (Download)

Datasheets (Download)

Add to compare

Product Properties

Manufacturer
Neomounts

Warranty
5 Years

SKU
WL95-800BL1

EAN
8717371440541

Design

Accepts padlock
No

Housing material
Steel

Product colour
Black

Ergonomics

Cable management
No

Depth adjustment
4 mm

Distance to the wall (max)
17.2 cm

Distance to the wall (min)
7.8 cm

Height adjustment
1.3 cm

Yes

Height adjustment range
0 - 13 mm

Height adjustment type
Manual

Swivelling
Yes

Tilt adjustment
Yes

Width adjustment
4 cm

Logistics data

Harmonized System (HS) code
7326909890

Master (outer) case gross weight
9.8 kg

Master (outer) case height
620 mm

Master (outer) case length
110 mm

Master (outer) case net weight
8.5 kg

Master (outer) case width
570 mm

Products per master (outer) case
1 pc(s)

Products per pallet (EU)
24 pc(s)

Quantity per master (outer) case
1 pc(s)

Mounting

Maximum screen size
177.8 cm (70")

Maximum VESA mount
600 x 400 mm

Maximum weight capacity
35 kg

Maximum weight capacity (per display)
35 kg

Minimum screen size
106.7 cm (42")

Minimum VESA mount
200 x 200 mm

Mounting type
Wall

Number of displays supported
1

Panel mounting interface
200 x 200,200 x 300,200 x 400,300 x 100,300 x 200,300 x 300,350 x 350,400 x 200,400 x 300,400 x 400,400 x 600,600 x 300,600 x 200,600 x 400

Other features

Country of origin
China

Depth adjustment range
0 - 4 mm

Packaging data

Package depth
110 mm

Package height
620 mm

Package type
Box

Package weight
9.8 kg

Package width
570 mm

Technical details

Easy to install
Yes

Orientation
Landscape/Portrait

Package net weight
9.8 kg

Warranty period
5 year(s)

Weight & dimensions

Depth
84 mm

Height
510 mm

Weight
7.72 kg

Width
620 mm

Width adjustment range
0 - 40 mm

Description

Neomounts WL95-800BL1 Videowall wall mount 42-70" - pop-out - max 35 kg. Maximum weight capacity: 35 kg, Minimum screen size: 106.7 cm (42"), Maximum screen size: 177.8 cm (70"), Minimum VESA mount: 200 x 200 mm, Maximum VESA mount: 600 x 400 mm. Height adjustment range: 0 - 13 mm. Product colour: Black

Maximum weight capacity: 35 kg Black
Maximum screen size: 177.8 cm (70")
Mounting type: Wall
Minimum VESA mount: 200 x 200 mm Maximum VESA mount: 600 x 400 mm
Height adjustment Swivelling
Housing material: Steel
Orientation: Landscape/Portrait
