NETGEAR GS316 Unmanaged L2 Gigabit Ethernet (10/100/1000) Black

Roll over image to zoom inClick to Open expanded view

NETGEAR GS316 Unmanaged L2 Gigabit Ethernet (10/100/1000) Black

Name: NETGEAR GS316 Unmanaged L2 Gigabit Ethernet (10/100/1000) Black
Brand: Netgear
SKU: GS316-300EUS

SKU: GS316-300EUS

Log In to View Pricing

Currently out of Stock

NETGEAR GS316, Unmanaged, L2, Gigabit Ethernet (10/100/1000), Wall mountable

Currently out of Stock

hypertec

Datasheets (Download)

Product manual (Download)

Add to compare

Product Properties

Manufacturer
Netgear

Warranty
3 Years

SKU
GS316-300EUS

EAN
606449164251

Bullet points

Point
802.1p QoS for traffic/frame prioritization

Auto-MDI/MDIX eliminates the need for crossover cables

Durable and rugged metal case

Energy-efficient technology for power savings

Fanless design for silent operation

Ideal for small office and home networks

LED indicators for ease of use

Non-blocking switching architecture for maximum throughput at wire speed

Plug-and-play; no setup required

Select between switches of various form factors

with GS324 and GS348 models

Data transmission

Jumbo frames
9216

Jumbo frames support
Yes

Latency (1 Gbps)
3.2 µs

MAC address table
16000 entries

Packet forwarding rate (1 Gbps)
1448000 pps

Switching capacity
32 Gbit/s

Design

Housing material
Metal

LED indicators
Yes

On/off switch
No

Product colour
Black

Rack mounting
No

Wall mountable
Yes

Management features

Quality of Service (QoS) support
Yes

Switch layer
L2

Switch type
Unmanaged

Network

10G support
No

Auto MDI/MDI-X
Yes

Auto-negotiation
Yes

Copper ethernet cabling technology
10BASE-T, 100BASE-TX, 1000BASE-T

Flow control support
Yes

Networking standards
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x

Operational conditions

Heat dissipation
27.7 BTU/h

Operating temperature (T-T)
0 - 40 °C

Storage relative humidity (H-H)
5 - 95%

Storage temperature (T-T)
-20 - 70 °C

Performance

Buffer size
512 KB

Fanless
Yes

Mean time between failures (MTBF)
4160957 h

Plug and Play
Yes

Ports & interfaces

Gigabit Ethernet (copper) ports quantity
16

Installed SFP modules quantity
0

Installed SFP+ modules quantity
0

Power connector
DC-in jack

Switch Number of Ports
16

Switch Port Speed
Gigabit Ethernet (10/100/1000)

Power

DC input voltage
12 V

Input current
1.5 A

Number of power supply units
1

Power consumption (max)
8.1 W

Power source
DC

Power over Ethernet (PoE)

Power over Ethernet (PoE)
No

Weight & dimensions

Depth
102 mm

Height
27 mm

Weight
890 g

Width
286 mm

Description

NETGEAR GS316. Switch type: Unmanaged, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 16. MAC address table: 16000 entries, Switching capacity: 32 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x. DC input voltage: 12 V. Power connector: DC-in jack. Wall mountable

Unmanaged L2
Quality of Service (QoS) support
Basic switching RJ-45 Ethernet ports quantity: 16
10BASE-T, 100BASE-TX, 1000BASE-T
MAC address table: 16000 entries Switching capacity: 32 Gbit/s
DC
Auto-MDI/MDIX eliminates the need for crossover cables
LED indicators for ease of use
Energy-efficient technology for power savings
Fanless design for silent operation
Auto-negotiation for automatic connection at the highest common speed between switch and an end device
Non-blocking switching architecture for maximum throughput at wire speed
802.1p QoS for traffic/frame prioritization
Plug-and-play; no setup required
Durable and rugged metal case
Select between switches of various form factors: desktop, wall mount or rack mount. Rack-mount kit included
with GS324 and GS348 models
Ideal for small office and home networks
Standards-based technology ensures interoperability with any standardsbased devices in the existing network
