NETGEAR GS516-300EUS network switch Unmanaged Gigabit Ethernet (10/100/1000) Grey

Roll over image to zoom inClick to Open expanded view

NETGEAR GS516-300EUS network switch Unmanaged Gigabit Ethernet (10/100/1000) Grey

Name: NETGEAR GS516-300EUS network switch Unmanaged Gigabit Ethernet (10/100/1000) Grey
Brand: Netgear
SKU: GS516-300EUS

SKU: GS516-300EUS

Log In to View Pricing

Currently out of Stock

NETGEAR GS516-300EUS, Unmanaged, Gigabit Ethernet (10/100/1000), Rack mounting

Currently out of Stock

hypertec

Datasheets (Download)

Add to compare

Product Properties

Manufacturer
Netgear

Warranty
3 Years

SKU
GS516-300EUS

EAN
606449164565

Certificates

Compliance certificates
BSMI, CB, CE, Federal Communications Commission (FCC), ISED, KC, RCM, UKCA, VCCI

Data transmission

Jumbo frames support
Yes

Latency (1 Gbps)
15 µs

Latency (10 Gbps)
35 µs

Latency (10-100 Mbps)
30 µs

MAC address table
8000 entries

Packet forwarding rate (1 Gbps)
1488000 pps

Switching capacity
32 Gbit/s

Design

Housing material
Metal

LED indicators
Activity, Link, Power, Speed

Product colour
Grey

Rack mounting
Yes

Management features

Quality of Service (QoS) support
Yes

Switch type
Unmanaged

Network

10G support
No

Auto MDI/MDI-X
Yes

Networking standards
IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3i, IEEE 802.3p, IEEE 802.3u

Operational conditions

Operating temperature (T-T)
0 - 50 °C

Storage temperature (T-T)
-20 - 70 °C

Ports & interfaces

Switch Number of Ports
16

Switch Port Speed
Gigabit Ethernet (10/100/1000)

Power

AC input frequency
50/60 Hz

AC input voltage
100 - 240 V

Power consumption (max)
10 W

Power supply included
Yes

Power over Ethernet (PoE)

Power over Ethernet (PoE)
No

Weight & dimensions

Depth
169 mm

Height
43 mm

Weight
1.49 kg

Width
328 mm

Description

NETGEAR GS516-300EUS. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 16. MAC address table: 8000 entries, Switching capacity: 32 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3i, IEEE 802.3p, IEEE.... Rack mounting

Unmanaged
Quality of Service (QoS) support
Basic switching RJ-45 Ethernet ports quantity: 16
MAC address table: 8000 entries Switching capacity: 32 Gbit/s
Rack mounting
Power supply included
