NETGEAR XS724TM Managed L2/L3/L4 Grey

Name: NETGEAR XS724TM Managed L2/L3/L4 Grey
Brand: Netgear
SKU: XS724TM-100EUS

SKU: XS724TM-100EUS

Log In to View Pricing

Currently out of Stock

NETGEAR XS724TM, Managed, L2/L3/L4, Full duplex, Rack mounting

Currently out of Stock

hypertec

Datasheets (Download)

Product manual (Download)

Add to compare

Product Properties

Manufacturer
Netgear

Warranty
Lifetime

SKU
XS724TM-100EUS

EAN
606449165579

Bullet points

Point
1-year of NETGEAR Insight Cloud Management included

24 x 10G/Multi-Gigabit ports with 4 dedicated SFP+ ports

Configurable L2+/Lite L3 network features

Energy Efficient Ethernet for maximum power savings

Quiet desktop or rackmount placement

Data transmission

Jumbo frames
9000

Jumbo frames support
Yes

MAC address table
16000 entries

Number of queues
8

Packet buffer memory
4 MB

Switching capacity
560 Gbit/s

Design

LED indicators
Yes

Number of fans
3 fan(s)

Product colour
Grey

Rack mounting
Yes

Management features

ARP inspection
Yes

Cloud-managed
Yes

Configuring Location Settings (CLI)
Yes

Quality of Service (QoS) support
Yes

Switch layer
L2/L3/L4

Switch type
Managed

Web-based management
Yes

Multicast features

Multicast Listener Discovery (MLD) snooping
MLD snooping support (v1 and v2)

Multicast support
Yes

Network

10G support
Yes

Broadcast storm control
Yes

Flow control support
Yes

Full duplex
Yes

IP routing
Yes

IPv4 routes
64

IPv6 routes
32

Link aggregation
Yes

Number of VLANs
512

Port mirroring
Yes

Rate limiting
Yes

Routing entries
64

Spanning tree protocol
Yes

VLAN support
Yes

Operational conditions

Heat dissipation
315.66 BTU/h

Operating altitude
0 - 3000 m

Operating relative humidity (H-H)
0 - 95%

Operating temperature (T-T)
0 - 50 °C

Storage relative humidity (H-H)
0 - 95%

Storage temperature (T-T)
-20 - 70 °C

Performance

Built-in processor
Yes

Firmware upgradeable
Yes

Flash memory
256 MB

Internal memory
1000 MB

Mean time between failures (MTBF)
408354.7 h

Memory type
RAM

Noise level
29.61 dB

Processor frequency
1250 MHz

Ports & interfaces

10G Ethernet (copper) ports quantity
24

SFP+ module slots quantity
4

Power

Power consumption (max)
92.5 W

Power source
AC

Power supply included
Yes

Protocols

GARP VLAN Registration Protocol (GVRP)
Yes

Security

Access Control List (ACL)
Yes

Access Control List (ACL) IPv6 entries
100

Authentication type
RADIUS

BPDU filtering/protection
Yes

DHCP features
DHCP client, DHCP server, DHCP snooping, DHCPv6 relay, DHCPv6 server

IGMP snooping
Yes

Loop protection
Yes

Password protection
Yes

Security algorithms
802.1x RADIUS, EAP

Weight & dimensions

Depth
204 mm

Height
43.2 mm

Weight
3.38 kg

Width
400 mm

Description

NETGEAR XS724TM. Switch type: Managed, Switch layer: L2/L3/L4. Full duplex. MAC address table: 16000 entries, Switching capacity: 560 Gbit/s. Rack mounting

Managed L2/L3/L4 Web-based management
Quality of Service (QoS) support Configuring Location Settings (CLI)
10G support
MAC address table: 16000 entries Switching capacity: 560 Gbit/s
Access Control List (ACL)
Rack mounting
AC Power supply included
24 x 10G/Multi-Gigabit ports with 4 dedicated SFP+ ports
Energy Efficient Ethernet for maximum power savings
Quiet desktop or rackmount placement
Configurable L2+/Lite L3 network features
1-year of NETGEAR Insight Cloud Management included
