• Design

• Chassis type
• Midi Tower

• Number of 3.5" bays
• 2

• Number of 5.25" bays
• 1

• Placement supported
• Vertical

• Product colour
• Black

• Expansion slots

• PCI Express x1 (Gen 2.x) slots
• 1

• PCI Express x16 (Gen 3.x) slots
• 3

• PCI Express x4 (Gen 2.x) slots
• 1

• PCI slots
• 1

• Filters

• Machinecategory
• Workstation

• Graphics

• Discrete graphics card memory
• 2.05 TB

• Discrete graphics card model
• NVIDIA® Quadro® K2000

• Memory

• ECC
• Yes

• Internal memory type
• DDR3-SDRAM

• Memory channels
• Quad-channel

• Memory clock speed
• 1866 MHz

• Memory Installed
• 16 GB

• Memory layout (slots x size)
• 4 x 4 GB

• Memory Slot Support
• 128 GB

• Memory slots
• 8x DIMM

• Non-ECC
• Yes

• Network

• Ethernet LAN
• Yes

• Ethernet LAN data rates
• 10,100,1000 Mbit/s

• Wi-Fi
• No

• Other features

• Optical drives quantity
• 1

• Packaging content

• Cables included
• AC

• Keyboard included
• No

• Manual
• Yes

• Mouse included
• No

• Performance

• Audio system
• HD

• Motherboard chipset
• Intel® C602

• Password protection
• Yes

• Password protection type
• BIOS, Supervisor, User

• Product type
• Workstation

• Ports & interfaces

• DVI port
• Yes

• Ethernet LAN (RJ-45) ports
• 1

• Headphone outputs
• 1

• Line-in
• Yes

• Line-out
• Yes

• Microphone in
• Yes

• PS/2 ports quantity
• 2

• Serial ports quantity
• 1

• USB 2.0 ports quantity
• 6

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 4

• Power

• Power supply
• 685 W

• Processor

• Bus type
• QPI

• ECC supported by processor
• Yes

• FSB Parity
• No

• Maximum internal memory supported by processor
• 256 GB

• Maximum number of PCI Express lanes
• 40

• Memory bandwidth supported by processor (max)
• 59.7 GB/s

• Memory clock speeds supported by processor
• 800,1066,1333,1600,1866 MHz

• Memory types supported by processor
• DDR3-SDRAM

• Number of Cores
• 6

• Number of processors installed
• 1

• PCI Express configurations
• x4, x8, x16

• PCI Express slots version
• 3.0

• Processor
• E5-1650V2

• Processor boost frequency
• 3.9 GHz

• Processor cache
• 12 MB

• Processor cache type
• Smart Cache

• Processor codename
• Ivy Bridge EP

• Processor family
• Intel® Xeon® E5 Family

• Processor frequency
• 3.5 GHz

• Processor lithography
• 22 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor series
• Intel Xeon E5-1600 v2

• Processor socket
• LGA 2011 (Socket R)

• Processor threads
• 12

• Tcase
• 70 °C

• Thermal Design Power (TDP)
• 130 W

• Processor special features

• Conflict-Free processor
• No

• CPU configuration (max)
• 1

• Embedded options available
• No

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Idle States
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• No

• Intel Demand Based Switching
• Yes

• Intel Dual Display Capable Technology
• No

• Intel Enhanced Halt State
• Yes

• Intel Fast Memory Access
• No

• Intel FDI Technology
• No

• Intel Flex Memory Access
• No

• Intel Identity Protection Technology version
• 0.00

• Intel Rapid Storage Technology
• No

• Intel Secure Key Technology version
• 1.00

• Intel Smart Connect Technology
• No

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• No

• Intel TSX-NI version
• 0.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Anti-Theft Technology (Intel® AT)
• No

• Intel® Clear Video HD Technology (Intel® CVT HD)
• No

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• No

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• No

• Intel® Insider™
• No

• Intel® InTru™ 3D Technology
• No

• Intel® My WiFi Technology (Intel® MWT)
• No

• Intel® OS Guard
• Yes

• Intel® Quick Sync Video Technology
• No

• Intel® Rapid Start Technology
• No

• Intel® Secure Key
• Yes

• Intel® Small Business Advantage (Intel® SBA)
• No

• Intel® Smart Cache
• Yes

• Intel® Smart Response Technology
• No

• Intel® Turbo Boost Technology
• 2.0

• Intel® Wireless Display (Intel® WiDi)
• No

• Processor ARK ID
• 75780

• Processor package size
• 52.5 x 45.0 mm

• Scalability
• 1S

• Supported instruction sets
• AVX

• Thermal Monitoring Technologies
• Yes

• Software

• Drivers included
• Yes

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 7 Professional

• Recovery operating system
• Windows 8

• Storage

• HDD capacity
• 2 TB

• HDD interface
• SATA

• HDD size
• 3.5"

• HDD speed
• 7200 RPM

• Number of HDDs installed
• 2

• Number of storage drives installed
• 2

• Number of storage drives supported
• 7

• Optical drive type
• DVD±RW

• RAID levels
• 0, 1, 5, 10

• RAID support
• Yes

• Storage Capacity
• 2 TB

• Storage type
• HDD

• Sustainability

• Sustainability certificates
• ENERGY STAR

• Weight & dimensions

• Depth
• 471 mm

• Height
• 414 mm

• Width
• 172.6 mm
