Synology SA SA3610 NAS Rack (2U) Intel® Xeon® D-1567 16 GB DDR4 144 TB HDD DiskStation Manager Black, Grey

Roll over image to zoom inClick to Open expanded view

Synology SA SA3610 NAS Rack (2U) Intel® Xeon® D-1567 16 GB DDR4 144 TB HDD DiskStation Manager Black, Grey

Name: Synology SA SA3610 NAS Rack (2U) Intel® Xeon® D-1567 16 GB DDR4 144 TB HDD DiskStation Manager Black, Grey
Brand: Synology
SKU: SA3610/144TB-HAT53

SKU: SA3610/144TB-HAT53

Non-Cancellable, Non-Returnable

Log In to View Pricing

ETA 10 days

Synology SA SA3610, NAS, Rack (2U), Intel® Xeon®, D-1567, 16 GB, DDR4

ETA 10 days

hypertec

Datasheets (Download)

Product manual (Download)

Add to compare

Product Properties

Manufacturer
Synology

Warranty
5years

Drive
With drives

SKU
SA3610/144TB-HAT53

EAN
5050914224134

Bullet points

Design

Built-in display
No

Built-in speaker(s)
No

Chassis type
Rack (2U)

Cooling type
Active

Fan diameter
8 cm

LED indicators
Alarm, Power, Status

Number of fans
4 fan(s)

Product colour
Black, Grey

Memory

ECC
Yes

Internal memory type
DDR4

Maximum RAM supported
128 GB

Memory form factor
RDIMM

Memory Installed
16 GB

Memory slots
4

Network

Copper ethernet cabling technology
10BASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-T

Ethernet LAN
Yes

Ethernet LAN data rate supported (max)
10000 Mbit/s

Ethernet LAN data rates
10,100,1000,10000 Mbit/s

iSCSI support
Yes

Link aggregation
Yes

Supported network protocols
SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, Fibre Channel, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV

Wake-on-LAN ready
Yes

Operational conditions

Operating relative humidity (H-H)
5 - 95%

Operating temperature (T-T)
0 - 35 °C

Storage relative humidity (H-H)
5 - 95%

Storage temperature (T-T)
-20 - 60 °C

Other features

Compliance certificates
BSMI, CCC, CE, EAC, Federal Communications Commission (FCC), KC, RoHS, UKCA, VCCI

Packaging content

Cables included
AC

Power cables quantity
2

Performance

Access Control List (ACL)
Yes

Backup features
Cloud, iSCSI LUN

Backup function
Yes

Browser supported
Google Chrome, Firefox, Microsoft Edge, Safari

Built-in FTP server
Yes

Built-in UPnP AV media server
Yes

Buzzer
Yes

Card reader integrated
No

Device class
Small & Medium Business

Hot spare
Yes

Management protocols
SNMP

Multilingual support
Yes

Noise level
49.8 dB

Number of users
16000 user(s)

On/off switch
Yes

Reset button
Yes

Security algorithms
AES, SSH, SSL/TLS

Share folder
SMB/AFP/FTP

Snapshot
Yes

System log
Yes

Type
NAS

Ports & interfaces

Ethernet LAN (RJ-45) ports
7

PCI Express x8 (Gen 3.x) slots
2

Serial ports quantity
1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2

USB port
Yes

Power

AC input frequency
50/60 Hz

AC input voltage
100 - 240 V

Number of power supply units
1

Power consumption (HDD standby)
58.23 W

Power consumption (typical)
137.54 W

Power supply location
Built-in

Power supply unit (PSU) capacity
550 W

Redundant power supply (RPS) support
Yes

Processor

Conflict-Free processor
Yes

CPU configuration (max)
1

Number of Cores
12

Number of processors supported
1

Processor
D-1567

Processor boost frequency
2.7 GHz

Processor cache
18 MB

Processor family
Intel® Xeon®

Processor frequency
2.1 GHz

Processor manufacturer
Intel

Processor threads
24

Processor special features

Embedded options available
Yes

Enhanced Intel SpeedStep Technology
Yes

Execute Disable Bit
Yes

Idle States
Yes

Intel 64
Yes

Intel Enhanced Halt State
Yes

Intel Secure Key Technology version
1.00

Intel Trusted Execution Technology
Yes

Intel TSX-NI
Yes

Intel TSX-NI version
1.00

Intel Virtualization Technology (VT-x)
Yes

Intel Virtualization Technology for Directed I/O (VT-d)
Yes

Intel VT-x with Extended Page Tables (EPT)
Yes

Software

Operating system installed
DiskStation Manager

Storage

Hot-swap drive bays
Yes

Installed storage drive type
HDD

Number of storage drives supported
12

Online RAID expansion
Yes

Online RAID migration
Yes

RAID levels
0, 1, 5, 6, 10, F1, JBOD

RAID support
Yes

Storage drive sizes supported
2.5,3.5"

Storage drives installed
Yes

Supported file systems
BTRFS, Fat, HFS+, NTFS, exFAT, ext3, ext4

Supported storage drive interfaces
Serial ATA, Serial Attached SCSI (SAS)

Supported storage drive types
HDD & SSD

Total installed storage capacity
144 TB

Sustainability

Sustainability certificates
UL ECOLOGO

Sustainability compliance
Yes

Weight & dimensions

Depth
724 mm

Height
88 mm

Width
482 mm

Description

Synology SA SA3610. Type: NAS. Chassis type: Rack (2U). Device class: Small & Medium Business. Processor family: Intel® Xeon®, Processor model: D-1567, Processor frequency: 2.1 GHz. Internal memory: 16 GB, Internal memory type: DDR4. Total installed storage capacity: 144 TB, Installed storage drive type: HDD. Operating system installed: DiskStation Manager

Small & Medium Business NAS Rack (2U) Black, Grey
DiskStation Manager
Total installed storage capacity: 144 TB Number of storage drives supported: 12 HDD & SSD Serial ATA, Serial Attached SCSI (SAS)
Intel® Xeon® D-1567 2.1 GHz
16 DDR4 Memory slots: 4 RDIMM ECC
Ethernet LAN 10000 iSCSI support Wake-on-LAN ready
Cooling type: Active
Backup features: Cloud, iSCSI LUN 550 W
Over 6,200/3,000 MB/s seq. read/write, built-in 10GbE, and hardware and software redundancy
Add up to 84 extra drive bays, 40GbE or Fibre Channel, and SSD cache volumes whenever needed
Back up 1,000+ endpoints, manage 128 IP cameras, or provide mailboxes for up to 1,600 users
