• Design

• Chassis type
• Rack (2U)

• Rack mounting
• Yes

• Rack rails
• Yes

• Redundant fans support
• Yes

• Expansion slots

• PCI Express slots version
• 3.0

• PCI Express x8 (Gen 3.x) slots
• 8

• Filters

• Machinecategory
• Server

• Graphics

• Maximum graphics card memory
• 16 MB

• On-board graphics card
• Yes

• Memory

• Internal memory type
• DDR4-SDRAM

• Memory Installed
• 16 GB

• Memory layout (slots x size)
• 1 x 16 GB

• Memory Slot Support
• 1.54 TB

• Memory slots
• 24

• Network

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet interface type
• Gigabit Ethernet

• Ethernet LAN
• Yes

• Operational conditions

• Operating altitude
• 0 - 3050 m

• Operating relative humidity (H-H)
• 8 - 85%

• Operating temperature (T-T)
• 5 - 40 °C

• Storage relative humidity (H-H)
• 8 - 85%

• Storage temperature (T-T)
• 5 - 45 °C

• Other features

• Graphics card
• G200eR2

• Graphics card family
• Matrox

• Integrated BMC with IPMI
• Yes

• Integrated LAN
• Yes

• Performance

• On-site support
• Yes

• Trusted Platform Module (TPM)
• Yes

• Trusted Platform Module (TPM) version
• 2.0

• Ports & interfaces

• Ethernet LAN (RJ-45) ports
• 4

• USB 2.0 ports quantity
• 1

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 2

• VGA (D-Sub) ports quantity
• 1

• Power

• Power supply
• 900 W

• Redundant power supply (RPS) support
• Yes

• Processor

• Bus type
• QPI

• Conflict-Free processor
• Yes

• ECC supported by processor
• Yes

• Embedded options available
• No

• Execute Disable Bit
• Yes

• Idle States
• Yes

• Maximum internal memory supported by processor
• 1.54 TB

• Maximum number of PCI Express lanes
• 40

• Memory bandwidth supported by processor (max)
• 76.8 GB/s

• Memory channels supported by processor
• Quad

• Memory clock speeds supported by processor
• 1600,1866,2133,2400 MHz

• Memory types supported by processor
• DDR4-SDRAM

• Number of Cores
• 18

• Number of processors installed
• 1

• Number of QPI links
• 2

• Physical Address Extension (PAE)
• 46 bit
  Yes

• Processor
• E5-2697V4

• Processor boost frequency
• 3.6 GHz

• Processor cache
• 45 MB

• Processor cache type
• Smart Cache

• Processor code
• SR2JV

• Processor codename
• Broadwell

• Processor family
• Intel® Xeon® E5 v4

• Processor frequency
• 2.3 GHz

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor package size
• 45 x 52.5 mm

• Processor series
• Intel Xeon E5-2600 v4

• Processor socket
• LGA 2011-v3

• Processor threads
• 36

• Scalability
• 2S

• Stepping
• B0

• Supported instruction sets
• AVX 2.0

• System bus rate
• 9.6 GT/s

• Tcase
• 79 °C

• Thermal Design Power (TDP)
• 145 W

• Thermal Monitoring Technologies
• Yes

• Processor special features

• CPU configuration (max)
• 2

• Enhanced Intel SpeedStep Technology
• Yes

• Intel 64
• Yes

• Intel Demand Based Switching
• Yes

• Intel Enhanced Halt State
• Yes

• Intel Flex Memory Access
• No

• Intel Identity Protection Technology version
• 0.00

• Intel Secure Key Technology version
• 1.00

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• Yes

• Intel TSX-NI version
• 1.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• No

• Intel® OS Guard
• Yes

• Intel® Secure Key
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Processor ARK ID
• 91755

• Software

• Compatible operating systems
• Microsoft Windows Server Red Hat Enterprise Linux SUSE Linux Enterprise Server VMware vSphere

• Operating system installed
• No

• Storage

• Hot-Plug support
• Yes

• Hot-swap
• Yes

• Maximum storage capacity
• 147.6 TB

• Optical drive type
• No

• RAID support
• Yes

• Supported storage drive interfaces
• SAS, Serial ATA

• Technical details

• Internal I/O Expansion Module x8 Gen 3
• 3

• Number of 2.5" bays
• 8

• Sustainability certificates
• ENERGY STAR

• Weight & dimensions

• Depth
• 800 mm

• Height
• 87 mm

• Weight
• 19 kg

• Width
• 446 mm
