• Audio

• Audio chip
• Realtek ALC3266CG

• Audio system
• Waves MaxxAudio Pro

• Built-in microphone
• Yes

• Built-in speaker(s)
• Yes

• RMS rated power
• 10 W

• Camera

• Built-in camera
• Yes

• Camera resolution
• 1280 x 720 pixels

• Total megapixels
• 1 MP

• Design

• Cable lock slot
• Yes

• Product colour
• Black, Grey

• Display

• HD type
• 4K Ultra HD

• LED backlight
• Yes

• Native aspect ratio
• 16:9

• Pixel pitch
• 0.144 x 0.144 mm

• Screen Resolution
• 3840 x 2160 pixels

• Screen shape
• Flat

• Screen Size
• 68.6 cm (27")

• Touchscreen
• No

• Filters

• Machinecategory
• Personal computer

• Graphics

• Discrete graphics card
• Yes

• Discrete graphics card memory
• 4 GB

• Discrete graphics card model
• AMD Radeon Pro WX 4150

• Maximum on-board graphics card memory
• 64 GB

• Number of displays supported (on-board graphics)
• 3

• On-board graphics card
• Yes

• On-board graphics card base frequency
• 350 MHz

• On-board graphics card DirectX version
• 12.0

• On-board graphics card dynamic frequency (max)
• 1150 MHz

• On-board graphics card ID
• 0x5912

• On-board graphics card model
• Intel® HD Graphics 630

• On-board graphics card OpenGL version
• 4.4

• Memory

• Internal memory type
• DDR4-SDRAM

• Memory clock speed
• 2400 MHz

• Memory form factor
• DIMM/SO-DIMM

• Memory Installed
• 8 GB

• Memory layout (slots x size)
• 1 x 8 GB

• Memory Slot Support
• 64 GB

• Memory slots
• 4

• Memory slots type
• SO-DIMM

• Network

• Bluetooth
• Yes

• Bluetooth version
• 4.1

• Ethernet LAN
• Yes

• Ethernet LAN data rates
• 10,100,1000 Mbit/s

• Top Wi-Fi standard
• Wi-Fi 5 (802.11ac)

• Wi-Fi
• Yes

• Wi-Fi standards
• 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)

• Operational conditions

• Operating altitude
• -15.2 - 3048 m

• Operating relative humidity (H-H)
• 10 - 90%

• Operating temperature (T-T)
• 0 - 35 °C

• Storage relative humidity (H-H)
• 0 - 95%

• Storage temperature (T-T)
• -40 - 65 °C

• Other features

• Autonomy mode
• No

• Dell E-Value Code
• N001P5720BTPWER

• Detachable display
• No

• Packaging content

• Cables included
• AC

• Drivers included
• Yes

• Keyboard included on selected markets only
• Yes

• Manual
• Yes

• Mouse included on selected markets only
• Yes

• Power cord included
• Yes

• Warranty card
• Yes

• Pen

• Pen included
• No

• Performance

• Market positioning
• Business

• Motherboard chipset
• Intel® C236

• Product type
• All-in-One workstation

• Trusted Platform Module (TPM)
• Yes

• Ports & interfaces

• Audio output
• Yes

• Combo headphone/mic port
• Yes

• DisplayPorts quantity
• 1

• Ethernet LAN (RJ-45) ports
• 1

• HDMI ports
• 1

• Microphone in
• No

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 5

• USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
• 2

• USB Sleep-and-Charge
• Yes

• USB Sleep-and-Charge ports
• 1

• Power

• AC adapter frequency
• 50/60 Hz

• AC adapter input voltage
• 100 - 240 V

• AC adapter power
• 360 W

• Processor

• Bus type
• DMI3

• Conflict-Free processor
• Yes

• ECC supported by processor
• No

• Maximum internal memory supported by processor
• 64 GB

• Maximum number of PCI Express lanes
• 16

• Memory channels supported by processor
• Dual

• Memory clock speeds supported by processor
• 1333,1600,2133,2400 MHz

• Memory types supported by processor
• DDR3L, DDR4-SDRAM

• Memory voltage supported by processor
• 1.35 V

• Number of Cores
• 4

• PCI Express configurations
• 1x16, 1x8+2x4, 2x8

• PCI Express slots version
• 3.0

• Processor
• i7-7700

• Processor boost frequency
• 4.2 GHz

• Processor cache
• 8 MB

• Processor cache type
• Smart Cache

• Processor code
• SR338

• Processor codename
• Kaby Lake

• Processor family
• Intel® Core™ i7

• Processor frequency
• 3.6 GHz

• Processor generation
• 7th gen Intel® Core™ i7

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor socket
• LGA 1151 (Socket H4)

• Processor threads
• 8

• Stepping
• B0

• System bus rate
• 8 GT/s

• Thermal Design Power (TDP)
• 65 W

• Tjunction
• 100 °C

• Processor special features

• CPU configuration (max)
• 1

• Embedded options available
• Yes

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Idle States
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• Yes

• Intel Enhanced Halt State
• Yes

• Intel Identity Protection Technology version
• 1.00

• Intel Secure Key Technology version
• 1.00

• Intel Software Guard Extensions (Intel SGX)
• Yes

• Intel Stable Image Platform Program (SIPP)
• Yes

• Intel Stable Image Platform Program (SIPP) version
• 1.00

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• Yes

• Intel TSX-NI version
• 1.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Clear Video HD Technology (Intel® CVT HD)
• Yes

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• Yes

• Intel® InTru™ 3D Technology
• Yes

• Intel® OS Guard
• Yes

• Intel® Quick Sync Video Technology
• Yes

• Intel® Secure Key
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Processor ARK ID
• 97128

• Processor package size
• 37.5 x 37.5 mm

• Scalability
• 1S

• Supported instruction sets
• AVX 2.0, SSE4.1, SSE4.2

• Thermal Monitoring Technologies
• Yes

• Thermal solution specification
• PCG 2015C

• Thunderbolt™ 3 Technology
• Yes

• Software

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 10 Pro

• Trial software
• Microsoft Office, McAfee

• Storage

• Card reader integrated
• Yes

• Compatible memory cards
• SD

• Number of SSDs installed
• 1

• Optical drive type
• No

• SSD capacity
• 256 GB

• Storage Capacity
• 256 GB

• Storage type
• SSD

• Sustainability

• Sustainability certificates
• ENERGY STAR

• Weight & dimensions

• Depth (with stand)
• 81.6 mm

• Height (with stand)
• 430.4 mm

• Weight (with stand)
• 13 kg

• Width (with stand)
• 613 mm
