• Design

• Chassis type
• Rack (4U)

• Rack mounting
• Yes

• Rack rails
• Yes

• Expansion slots

• PCI Express slots version
• 3.0

• Filters

• Machinecategory
• Server

• Graphics

• Maximum graphics card memory
• 16 MB

• On-board graphics card
• No

• On-board graphics card model
• Not available

• Memory

• ECC
• Yes

• Internal memory type
• DDR3-SDRAM

• Memory clock speed
• 1600 MHz

• Memory Installed
• 64 GB

• Memory layout (slots x size)
• 4 x 16 GB

• Memory Slot Support
• 6.14 TB

• Memory slots
• 96

• Network

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet interface type
• 10 Gigabit Ethernet, Gigabit Ethernet

• Ethernet LAN
• Yes

• Operational conditions

• Non-operating altitude
• 0 - 3050 m

• Operating altitude
• 0 - 3050 m

• Operating relative humidity (H-H)
• 8 - 85%

• Operating temperature (T-T)
• 5 - 40 °C

• Storage relative humidity (H-H)
• 8 - 85%

• Storage temperature (T-T)
• 5 - 45 °C

• Other features

• Graphics card
• G200eR2

• Graphics card family
• Matrox

• Intel® Virtualization Technology (Intel® VT)
• VT-d, VT-x

• Security features
• Power-on, admin password

• Performance

• BIOS type
• UEFI

• Noise level
• 6.6 dB

• Trusted Platform Module (TPM)
• Yes

• Trusted Platform Module (TPM) version
• 1.2

• Ports & interfaces

• Serial ports quantity
• 1

• USB 2.0 ports quantity
• 5

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 2

• VGA (D-Sub) ports quantity
• 2

• Power

• Number of main power supplies
• 2

• Number of redundant power supplies installed
• 2

• Number of redundant power supplies supported
• 4

• Power supply
• 900 W

• Power supply input frequency
• 50 - 60 Hz

• Redundant power supply (RPS) support
• Yes

• Processor

• Bus type
• QPI

• Conflict-Free processor
• Yes

• ECC supported by processor
• Yes

• Embedded options available
• No

• Execute Disable Bit
• Yes

• FSB Parity
• No

• Idle States
• Yes

• Intel Remote Management Module Support
• IMM2

• Intelligent Platform Management Interface (IPMI) support
• Yes

• Maximum internal memory supported by processor
• 1.54 TB

• Maximum number of PCI Express lanes
• 32

• Maximum number of SMP processors
• 4

• Memory bandwidth supported by processor (max)
• 102 GB/s

• Memory channels supported by processor
• Quad

• Memory clock speeds supported by processor
• 1333,1600,1800,1066 MHz

• Memory types supported by processor
• DDR4-SDRAM, DDR3-SDRAM

• Number of Cores
• 14

• Number of processors installed
• 2

• Number of QPI links
• 3

• PCI Express configurations
• x4, x8, x16

• Physical Address Extension (PAE)
• 46 bit
  Yes

• Processor
• E7-4850V3

• Processor boost frequency
• 2.8 GHz

• Processor cache
• 35 MB

• Processor cache type
• Last Level Cache

• Processor code
• SR221

• Processor codename
• Haswell

• Processor family
• Intel® Xeon® E7 v3

• Processor frequency
• 2.2 GHz

• Processor lithography
• 22 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor package size
• 52 x 45 mm

• Processor series
• Intel Xeon E7-4800 v3

• Processor socket
• LGA 2011 (Socket R)

• Processor threads
• 28

• Scalability
• S4S

• Stepping
• E0

• Supported instruction sets
• AVX 2.0

• Supported processor sockets
• LGA 2011 (Socket R)

• System bus rate
• 8 GT/s

• Tcase
• 70 °C

• Thermal Design Power (TDP)
• 115 W

• Thermal Monitoring Technologies
• Yes

• Processor special features

• CPU configuration (max)
• 4

• Enhanced Intel SpeedStep Technology
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• No

• Intel Demand Based Switching
• No

• Intel Dual Display Capable Technology
• No

• Intel Enhanced Halt State
• Yes

• Intel Fast Memory Access
• No

• Intel FDI Technology
• No

• Intel Flex Memory Access
• No

• Intel Instruction Replay Technology
• No

• Intel Instruction Replay Technology version
• 0.00

• Intel Rapid Storage Technology
• No

• Intel Secure Key Technology version
• 1.00

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• Yes

• Intel TSX-NI version
• 1.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Anti-Theft Technology (Intel® AT)
• No

• Intel® Clear Video HD Technology (Intel® CVT HD)
• No

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• No

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Insider™
• No

• Intel® InTru™ 3D Technology
• No

• Intel® My WiFi Technology (Intel® MWT)
• No

• Intel® OS Guard
• Yes

• Intel® Quick Sync Video Technology
• No

• Intel® Secure Key
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Intel® Wireless Display (Intel® WiDi)
• No

• Processor ARK ID
• 84679

• Software

• Compatible operating systems
• Microsoft Windows Server, Red Hat Enterprise Linux Server, SUSE Linux Enterprise Server, VMware vSphere Hypervisor

• Operating system installed
• No

• Storage

• HDD interface
• Serial ATA, Serial Attached SCSI (SAS)

• HDD size
• 2.5"

• Hot-swap
• Yes

• Maximum storage capacity
• 12.8 TB

• Number of HDDs supported
• 8

• Number of SSDs supported
• 8

• Optical drive type
• No

• RAID levels
• 1, 10

• RAID support
• Yes

• Weight & dimensions

• Depth
• 804 mm

• Height
• 173 mm

• Width
• 482 mm
