• Design

• Chassis type
• Blade

• Features

• Images Type Map
•

• Filters

• Machinecategory
• Server

• Graphics

• On-board graphics card
• Yes

• Memory

• Internal memory type
• DDR3L-SDRAM

• Memory clock speed
• 1066 MHz

• Memory Installed
• 256 GB

• Memory layout (slots x size)
• 16 x 16 GB

• Memory Slot Support
• 512 GB

• Memory slots
• 16

• Network

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet interface type
• 10 Gigabit Ethernet, Gigabit Ethernet

• Ethernet LAN
• Yes

• LAN controller
• Broadcom BCM5709S

• Wake-on-LAN ready
• Yes

• Operational conditions

• Operating altitude
• 0 - 2133 m

• Operating relative humidity (H-H)
• 8 - 80%

• Operating temperature (T-T)
• 10 - 35 °C

• Other features

• Fibre Channel
• Yes

• Graphics card
• G200e

• Graphics card family
• Matrox

• Performance

• Trusted Platform Module (TPM)
• Yes

• Trusted Platform Module (TPM) version
• 1.2

• Ports & interfaces

• Ethernet LAN (RJ-45) ports
• 4

• VGA (D-Sub) ports quantity
• 1

• Processor

• Bus type
• QPI

• Conflict-Free processor
• No

• CPU multiplier (bus/core ratio)
• 16

• ECC supported by processor
• Yes

• Embedded options available
• No

• Execute Disable Bit
• Yes

• FSB Parity
• No

• Maximum internal memory supported by processor
• 1.02 TB

• Maximum number of SMP processors
• 2

• Memory channels supported by processor
• Quad

• Memory clock speeds supported by processor
• 800,978,1066,1333 MHz

• Memory types supported by processor
• DDR3-SDRAM

• Number of Cores
• 8

• Number of processors installed
• 2

• Processor
• E7-2830

• Processor boost frequency
• 2.4 GHz

• Processor cache
• 24 MB

• Processor cache type
• Smart Cache

• Processor code
• SLC3J

• Processor codename
• Westmere EX

• Processor family
• Intel® Xeon® E7 Family

• Processor frequency
• 2.13 GHz

• Processor lithography
• 32 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor package size
• 49.17 x 56.47 mm

• Processor series
• Intel Xeon E7-2800

• Processor socket
• LGA 1567 (Socket LS)

• Processor threads
• 16

• Scalability
• S2S

• Stepping
• A2

• Supported instruction sets
• SSE4.1, SSE4.2

• System bus rate
• 6.4 GT/s

• Tcase
• 64 °C

• Thermal Design Power (TDP)
• 105 W

• Thermal Monitoring Technologies
• Yes

• Processor special features

• CPU configuration (max)
• 2

• Enhanced Intel SpeedStep Technology
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• No

• Intel Demand Based Switching
• No

• Intel Dual Display Capable Technology
• No

• Intel Enhanced Halt State
• No

• Intel Fast Memory Access
• No

• Intel FDI Technology
• No

• Intel Flex Memory Access
• No

• Intel Rapid Storage Technology
• No

• Intel Trusted Execution Technology
• Yes

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Anti-Theft Technology (Intel® AT)
• No

• Intel® Clear Video HD Technology (Intel® CVT HD)
• No

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• No

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Insider™
• No

• Intel® InTru™ 3D Technology
• No

• Intel® My WiFi Technology (Intel® MWT)
• No

• Intel® Quick Sync Video Technology
• No

• Intel® Turbo Boost Technology
• 1.0

• Intel® Wireless Display (Intel® WiDi)
• No

• Processor ARK ID
• 53674

• Software

• Compatible operating systems
• Microsoft Windows, Red Hat Linux, SUSE Linux, VMware

• Operating system installed
• No

• Storage

• Hot-swap
• No

• Maximum storage capacity
• 0.8 TB

• Number of SSDs installed
• 2

• Number of SSDs supported
• 2

• Optical drive type
• No

• SSD capacity
• 200 GB

• SSD interface
• SATA

• Storage Capacity
• 400 GB

• Supported HDD sizes
• 1.8"

• Supported storage drive interfaces
• Serial ATA

• Weight & dimensions

• Depth
• 446 mm

• Height
• 245 mm

• Width
• 30 mm
