• Audio

• Audio system
• DTS Studio Sound

• Built-in microphone
• Yes

• Number of built-in speakers
• 2

• Battery

• Battery capacity
• 44 Wh

• Battery technology
• Lithium Polymer (LiPo)

• Number of battery cells
• 6

• Camera

• Front camera
• Yes

• Design

• Country of origin
• China

• Form factor
• Convertible (Swivel)

• Product colour
• Silver

• Product type
• Hybrid (2-in-1)

• Display

• HD type
• HD

• LED backlight
• Yes

• Native aspect ratio
• 16:9

• Screen Resolution
• 1366 x 768 pixels

• Screen Size
• 29.5 cm (11.6")

• Touch technology
• Multi-touch

• Touchscreen
• Yes

• Touchscreen type
• Capacitive

• Filters

• Machinecategory
• Notebook

• Graphics

• Discrete graphics card
• No

• Discrete graphics card model
• Not available

• Maximum on-board graphics card memory
• 1.74 GB

• On-board graphics card
• Yes

• On-board graphics card base frequency
• 200 MHz

• On-board graphics card DirectX version
• 12

• On-board graphics card dynamic frequency (max)
• 1100 MHz

• On-board graphics card family
• Intel® HD Graphics

• On-board graphics card ID
• 0xA16

• On-board graphics card model
• Intel® HD Graphics 4400

• Keyboard

• Numeric keypad
• No

• Pointing device
• Touchpad

• Memory

• Internal memory type
• DDR3-SDRAM

• Memory clock speed
• 1600 MHz

• Memory form factor
• On-board

• Memory Installed
• 4 GB

• Memory Slot Support
• 12 GB

• Memory slots
• 1x SO-DIMM

• Network

• Bluetooth
• Yes

• Bluetooth version
• 4.0

• Ethernet LAN
• Yes

• Top Wi-Fi standard
• Wi-Fi 4 (802.11n)

• Wi-Fi
• Yes

• Wi-Fi standards
• 802.11a, 802.11b, 802.11g

• Operational conditions

• Operating relative humidity (H-H)
• 20 - 80%

• Operating temperature (T-T)
• 5 - 35 °C

• Storage relative humidity (H-H)
• 10 - 90%

• Storage temperature (T-T)
• -15 - 60 °C

• Other features

• AC adapter included
• Yes

• LightScribe
• No

• Packaging content

• Manual
• Yes

• Quick start guide
• Yes

• Warranty card
• Yes

• Performance

• Accelerometer
• Yes

• Ambient light sensor
• Yes

• Ports & interfaces

• CardBus PCMCIA slot type
• No

• Charging port type
• DC-in jack

• Combo headphone/mic port
• Yes

• DisplayPorts quantity
• 1

• Docking connector
• Yes

• DVI port
• No

• Ethernet LAN (RJ-45) ports
• 1

• ExpressCard slot
• No

• Microphone in
• No

• S/PDIF out port
• No

• SATA Ports
• 4

• SmartCard slot
• No

• Total number of SATA connectors
• 4

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 2

• Power

• AC adapter frequency
• 50 - 60 Hz

• AC adapter input voltage
• 100 - 240 V

• AC adapter power
• 45 W

• Processor

• Bus type
• DMI2

• ECC supported by processor
• No

• FSB Parity
• No

• Maximum number of PCI Express lanes
• 12

• Motherboard chipset
• Intel® QM87

• Number of Cores
• 2

• PCI Express configurations
• 4x1, 2x4

• PCI Express slots version
• 2.0

• Processor
• i5-4300U

• Processor boost frequency
• 2.9 GHz

• Processor cache
• 3 MB

• Processor cache type
• Smart Cache

• Processor codename
• Haswell

• Processor family
• Intel® Core™ i5

• Processor frequency
• 1.9 GHz

• Processor generation
• 4th gen Intel® Core™ i5

• Processor lithography
• 22 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor series
• Intel Core i5-4300 Mobile series

• Processor socket
• BGA 1168

• Processor threads
• 4

• Stepping
• D0

• System bus rate
• 5 GT/s

• Thermal Design Power (TDP)
• 15 W

• Tjunction
• 100 °C

• Processor special features

• Conflict-Free processor
• Yes

• CPU configuration (max)
• 1

• Embedded options available
• Yes

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Idle States
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• No

• Intel Demand Based Switching
• No

• Intel Dual Display Capable Technology
• No

• Intel Enhanced Halt State
• Yes

• Intel Fast Memory Access
• No

• Intel FDI Technology
• No

• Intel Flex Memory Access
• No

• Intel Identity Protection Technology version
• 1.00

• Intel ME Firmware Version
• 9.5

• Intel Rapid Storage Technology
• Yes

• Intel Secure Key Technology version
• 1.00

• Intel Small Business Advantage (SBA) version
• 1.00

• Intel Smart Connect Technology
• Yes

• Intel Smart Connect Technology version
• 1.00

• Intel Smart Response Technology version
• 1.00

• Intel Stable Image Platform Program (SIPP)
• Yes

• Intel Stable Image Platform Program (SIPP) version
• 1.00

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• No

• Intel TSX-NI version
• 0.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® Active Management Technology (Intel® AMT)
• No

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Anti-Theft Technology (Intel® AT)
• Yes

• Intel® Clear Video HD Technology (Intel® CVT HD)
• Yes

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• No

• Intel® High Definition Audio (Intel® HD Audio)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• Yes

• Intel® Insider™
• Yes

• Intel® InTru™ 3D Technology
• Yes

• Intel® Matrix Storage Technology (Intel® MST)
• No

• Intel® My WiFi Technology (Intel® MWT)
• No

• Intel® Quick Sync Video Technology
• Yes

• Intel® Rapid Start Technology
• No

• Intel® Secure Key
• Yes

• Intel® Small Business Advantage (Intel® SBA)
• Yes

• Intel® Smart Cache
• Yes

• Intel® Smart Response Technology
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Intel® Wireless Display (Intel® WiDi)
• Yes

• Processor ARK ID
• 76308

• Processor code
• SR1ED

• Processor package size
• 40 x 24 x 1.5 mm

• Supported instruction sets
• AVX 2.0, SSE4.1, SSE4.2

• Thermal Monitoring Technologies
• Yes

• UART
• Yes

• Security

• Cable lock slot
• Yes

• Trusted Platform Module (TPM)
• Yes

• Software

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 7 Professional

• Recovery operating system
• Windows 8.1 Pro

• Storage

• Card reader integrated
• Yes

• Compatible memory cards
• MicroSD (TransFlash)

• Number of SSDs installed
• 1

• Optical drive type
• No

• SSD capacity
• 180 GB

• Storage Capacity
• 180 GB

• Storage type
• SSD

• Total SSDs capacity
• 180 GB

• Sustainability

• Sustainability certificates
• RoHS, ENERGY STAR

• Weight & dimensions

• Depth
• 285 mm

• Height
• 22.2 mm

• Weight
• 1.4 kg

• Width
• 212 mm
