• Design

• Chassis type
• Tower (4U)

• Product colour
• Black

• Redundant fans support
• No

• Expansion slots

• PCI Express slots version
• 3.0

• Filters

• Machinecategory
• Server

• Graphics

• On-board graphics card model
• Not available

• Logistics data

• Harmonized System (HS) code
• 84714100

• Memory

• ECC
• Yes

• Internal memory type
• DDR4-SDRAM

• Memory clock speed
• 2666 MHz

• Memory Installed
• 16 GB

• Memory layout (slots x size)
• 1 x 16 GB

• Memory Slot Support
• 64 GB

• Memory slots
• 4x DIMM

• Network

• Ethernet interface type
• Gigabit Ethernet

• Ethernet LAN
• Yes

• Performance

• Remote administration
• iLO 5 ASIC

• Trusted Platform Module (TPM)
• Yes

• Trusted Platform Module (TPM) version
• 2.0

• Ports & interfaces

• Ethernet LAN (RJ-45) ports
• 2

• USB 2.0 ports quantity
• 1

• VGA (D-Sub) ports quantity
• 1

• Power

• Number of main power supplies
• 1

• Power supply
• 350 W

• Redundant power supply (RPS) support
• No

• Processor

• Embedded options available
• No

• Execute Disable Bit
• Yes

• Idle States
• Yes

• Maximum internal memory supported by processor
• 128 GB

• Maximum number of PCI Express lanes
• 16

• Memory clock speeds supported by processor
• 2666 MHz

• Memory types supported by processor
• DDR4-SDRAM

• Motherboard chipset
• Intel C246

• Number of Cores
• 4

• Number of processors installed
• 1

• PCI Express configurations
• 1x16, 2x8, 1x8+2x4

• Processor
• E-2234

• Processor boost frequency
• 4.8 GHz

• Processor cache
• 8 MB

• Processor cache type
• Smart Cache

• Processor codename
• Coffee Lake

• Processor family
• Intel Xeon E

• Processor frequency
• 3.6 GHz

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor package size
• 37.5 x 37.5 mm

• Processor socket
• LGA 1151 (Socket H4)

• Processor threads
• 8

• Scalability
• 1S

• Supported instruction sets
• SSE4.1, SSE4.2, AVX 2.0

• Tcase
• 69.3 °C

• Thermal Design Power (TDP)
• 71 W

• Thermal Monitoring Technologies
• Yes

• Tjunction
• 100 °C

• Processor special features

• CPU configuration (max)
• 1

• Enhanced Intel SpeedStep Technology
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• No

• Intel Software Guard Extensions (Intel SGX)
• Yes

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• Yes

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Clear Video HD Technology (Intel® CVT HD)
• No

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® InTru™ 3D Technology
• No

• Intel® OS Guard
• Yes

• Intel® Quick Sync Video Technology
• No

• Intel® Secure Key
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Processor ARK ID
• 191039

• Software

• Compatible operating systems
• Microsoft Windows Server 2016 & 2019 Red Hat Enterprise Linux (RHEL) 7.5 & 8.0 SUSE Linux Enterprise Server (SLES) 12 SP3 & 15 VMware ESXi 6.5 U2 & 6.7 ClearOS CentOS

• Operating system installed
• No

• Storage

• HDD interface
• Serial ATA

• HDD size
• 3.5"

• Hot-Plug support
• Yes

• Maximum storage capacity
• 56 TB

• Number of HDDs supported
• 4

• Optical drive type
• No

• RAID levels
• 0, 1, 5, 10

• RAID support
• Yes

• Weight & dimensions

• Depth
• 475 mm

• Height
• 368.3 mm

• Width
• 175 mm
