• Design

• Chassis type
• Tower

• Expansion slots

• PCI Express slots version
• 3.0

• PCI Express x1 slots
• 1

• PCI Express x4 slots
• 1

• PCI Express x8 slots
• 2

• Filters

• Machinecategory
• Server

• Graphics

• Maximum graphics card memory
• 8 MB

• On-board graphics card model
• Not available

• Memory

• ECC
• Yes

• Internal memory type
• DDR3-SDRAM

• Memory clock speed
• 1600 MHz

• Memory Installed
• 4 GB

• Memory layout (slots x size)
• 1 x 4 GB

• Memory Slot Support
• 32768 MB
  32 GB

• Memory slots
• 4x DIMM

• Network

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet interface type
• Gigabit Ethernet

• Ethernet LAN
• Yes

• LAN controller
• Broadcom BCM5722

• Other features

• Graphics card
• G200eW

• Graphics card family
• Matrox

• Integrated BMC with IPMI
• Yes

• Performance

• Performance management
• IPMI 2.0, Dell OpenManage

• Trusted Platform Module (TPM)
• Yes

• Ports & interfaces

• Ethernet LAN (RJ-45) ports
• 1

• Serial ports quantity
• 1

• USB 2.0 ports quantity
• 6

• VGA (D-Sub) ports quantity
• 1

• Power

• Number of main power supplies
• 1

• Power supply
• 305 W

• Redundant power supply (RPS) support
• No

• Processor

• Bus type
• DMI

• Compatible processor series
• Intel® Xeon®

• Conflict-Free processor
• No

• CPU multiplier (bus/core ratio)
• 31

• ECC supported by processor
• Yes

• Embedded options available
• No

• Execute Disable Bit
• Yes

• FSB Parity
• No

• Idle States
• Yes

• Intelligent Platform Management Interface (IPMI) support
• Yes

• Maximum internal memory supported by processor
• 32 GB

• Maximum number of SMP processors
• 1

• Memory bandwidth supported by processor (max)
• 25.6 GB/s

• Memory channels supported by processor
• Dual

• Memory clock speeds supported by processor
• 1333,1600 MHz

• Memory types supported by processor
• DDR3-SDRAM

• Motherboard chipset
• Intel® C202

• Number of Cores
• 4

• Number of processors installed
• 1

• PCI Express configurations
• 1x16+1x4, 1x8+3x4, 2x8+1x4

• Processor
• E3-1220V2

• Processor boost frequency
• 3.5 GHz

• Processor cache
• 8 MB

• Processor cache type
• Smart Cache

• Processor code
• SR0PH

• Processor codename
• Ivy Bridge

• Processor family
• Intel® Xeon® E3 V2 Family

• Processor frequency
• 3.1 GHz

• Processor lithography
• 22 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor package size
• 37.5 x 37.5 mm

• Processor series
• Intel Xeon E3-1200 v2

• Processor socket
• LGA 1155 (Socket H2)

• Processor threads
• 4

• Stepping
• E1

• Supported instruction sets
• AVX, SSE4.1, SSE4.2

• System bus rate
• 5 GT/s

• Thermal Design Power (TDP)
• 69 W

• Thermal Monitoring Technologies
• Yes

• Processor special features

• CPU configuration (max)
• 1

• Enhanced Intel SpeedStep Technology
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• No

• Intel Demand Based Switching
• Yes

• Intel Dual Display Capable Technology
• No

• Intel Enhanced Halt State
• Yes

• Intel Fast Memory Access
• Yes

• Intel FDI Technology
• No

• Intel Flex Memory Access
• Yes

• Intel Identity Protection Technology version
• 1.00

• Intel Rapid Storage Technology
• No

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• No

• Intel TSX-NI version
• 0.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Anti-Theft Technology (Intel® AT)
• No

• Intel® Clear Video HD Technology (Intel® CVT HD)
• No

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• No

• Intel® Hyper Threading Technology (Intel® HT Technology)
• No

• Intel® Identity Protection Technology (Intel® IPT)
• Yes

• Intel® Insider™
• No

• Intel® InTru™ 3D Technology
• No

• Intel® My WiFi Technology (Intel® MWT)
• No

• Intel® Quick Sync Video Technology
• No

• Intel® Smart Cache
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Intel® Wireless Display (Intel® WiDi)
• No

• Processor ARK ID
• 65734

• Software

• Compatible operating systems
• Windows Small Business Server 2011 Windows Server 2008 Foundation R2 SP1 Windows Server 2008 SP2, (x86/x64) Windows Server 2008 R2 SP1 (x64) Novell SUSE Linux Enterprise Server Red Hat Enterprise Linux Citrix XenServer VMware vSphere ESXi Red Hat Enterprise Virtualization

• Storage

• HDD capacity
• 1 TB

• HDD interface
• Serial ATA

• HDD size
• 3.5"

• HDD speed
• 7200 RPM

• Internal drive bays
• 4

• Maximum storage capacity
• 12 TB

• Number of HDDs installed
• 1

• Number of HDDs supported
• 4

• Optical drive type
• DVD-RW

• Storage Capacity
• 1 TB

• Supported HDD sizes
• 3.5"

• Supported storage drive interfaces
• Serial ATA

• Weight & dimensions

• Depth
• 420.3 mm

• Height
• 463.8 mm

• Width
• 189.3 mm
