• Design

• Chassis type
• Rack (1U)

• Rack mounting
• Yes

• Expansion slots

• PCI Express slots version
• 3.0

• PCI Express x8 (Gen 3.x) slots
• 1

• Filters

• Machinecategory
• Server

• Graphics

• Number of displays supported (on-board graphics)
• 3

• On-board graphics card
• Yes

• On-board graphics card base frequency
• 350 MHz

• On-board graphics card dynamic frequency (max)
• 1200 MHz

• On-board graphics card family
• Intel® HD Graphics

• On-board graphics card model
• Intel® HD Graphics P4600

• Memory

• Buffered memory type
• Unregistered (unbuffered)

• Internal memory type
• DDR3-SDRAM

• Memory clock speed
• 1600 MHz

• Memory Installed
• 8 GB

• Memory layout (slots x size)
• 2 x 4 GB

• Memory Slot Support
• 32 GB

• Memory slots
• 4x DIMM

• Network

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet interface type
• Fast Ethernet, Gigabit Ethernet

• Ethernet LAN
• Yes

• LAN controller
• Intel® I217

• Operational conditions

• Operating temperature (T-T)
• 10 - 35 °C

• Storage temperature (T-T)
• -10 - 60 °C

• Other features

• Graphics card
• HD Graphics P4600

• Graphics card family
• Intel

• Ports & interfaces

• DisplayPorts quantity
• 1

• Ethernet LAN (RJ-45) ports
• 3

• Serial ports quantity
• 1

• USB 2.0 ports quantity
• 4

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 4

• VGA (D-Sub) ports quantity
• 1

• Power

• Number of main power supplies
• 1

• Power supply
• 300 W

• Redundant power supply (RPS) support
• No

• Processor

• Bus type
• QPI

• Conflict-Free processor
• No

• ECC supported by processor
• Yes

• Embedded options available
• Yes

• Execute Disable Bit
• Yes

• FSB Parity
• No

• Graphics & IMC lithography
• 22 nm

• Idle States
• Yes

• Maximum internal memory supported by processor
• 32 GB

• Maximum number of PCI Express lanes
• 16

• Maximum number of SMP processors
• 1

• Memory bandwidth supported by processor (max)
• 25.6 GB/s

• Memory channels supported by processor
• Dual

• Memory clock speeds supported by processor
• 1333,1600 MHz

• Memory types supported by processor
• DDR3-SDRAM

• Motherboard chipset
• Intel® C226

• Number of Cores
• 4

• Number of processors installed
• 1

• Number of QPI links
• 1

• PCI Express configurations
• 1x16, 2x8, 1x8+2x4

• Processor
• E3-1225V3

• Processor boost frequency
• 3.6 GHz

• Processor cache
• 8 MB

• Processor cache type
• Smart Cache

• Processor code
• SR14U

• Processor codename
• Haswell

• Processor family
• Intel® Xeon® E3 V3 Family

• Processor frequency
• 3.2 GHz

• Processor lithography
• 22 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor package size
• 37.5 x 37.5 mm

• Processor series
• Intel Xeon E3-1200 v3

• Processor socket
• LGA 1150 (Socket H3)

• Processor threads
• 4

• Scalability
• 1S

• Stepping
• C0

• Supported instruction sets
• AVX 2.0, SSE4.1, SSE4.2

• Thermal Design Power (TDP)
• 84 W

• Thermal Monitoring Technologies
• Yes

• Thermal solution specification
• PCG 2013D

• Processor special features

• CPU configuration (max)
• 1

• Enhanced Intel SpeedStep Technology
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• No

• Intel Demand Based Switching
• No

• Intel Dual Display Capable Technology
• Yes

• Intel Enhanced Halt State
• Yes

• Intel Fast Memory Access
• Yes

• Intel FDI Technology
• Yes

• Intel Flex Memory Access
• Yes

• Intel Identity Protection Technology version
• 1.00

• Intel Rapid Storage Technology
• No

• Intel Secure Key Technology version
• 1.00

• Intel Stable Image Platform Program (SIPP)
• Yes

• Intel Stable Image Platform Program (SIPP) version
• 1.00

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• Yes

• Intel TSX-NI version
• 1.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Anti-Theft Technology (Intel® AT)
• Yes

• Intel® Clear Video HD Technology (Intel® CVT HD)
• Yes

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• No

• Intel® Hyper Threading Technology (Intel® HT Technology)
• No

• Intel® Identity Protection Technology (Intel® IPT)
• Yes

• Intel® Insider™
• No

• Intel® InTru™ 3D Technology
• Yes

• Intel® My WiFi Technology (Intel® MWT)
• No

• Intel® OS Guard
• Yes

• Intel® Quick Sync Video Technology
• Yes

• Intel® Secure Key
• Yes

• Intel® Smart Cache
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Intel® Wireless Display (Intel® WiDi)
• No

• Processor ARK ID
• 75461

• Software

• Compatible operating systems
• Windows Server 2012 R2 Windows Server 2012 Windows Server 2008 R2 Windows Small Business Server 2011 Red Hat Enterprise Linux 6.5 SUSE Linux Enterprise Server 11 VMware vSphere 5.5 (ESXi)

• Operating system installed
• No

• Storage

• HDD interface
• Serial ATA III

• HDD size
• 3.5"

• HDD speed
• 7200 RPM

• Number of HDDs installed
• 2

• Number of HDDs supported
• 2

• Optical drive type
• DVD±RW

• RAID levels
• 0, 1, 10

• RAID support
• Yes

• Storage Capacity
• 1 TB

• Weight & dimensions

• Depth
• 411.5 mm

• Height
• 43.4 mm

• Weight
• 7.35 kg

• Width
• 429.3 mm
