• Design

• Chassis type
• Tower (5U)

• Rack mounting
• Yes

• Rack rails
• Yes

• Redundant fans support
• Yes

• Expansion slots

• PCI Express slots version
• 3.0

• PCI Express x16 slots
• 4

• PCI Express x4 slots
• 1

• PCI Express x8 slots
• 2

• Features

• Images Type Map
•

• Filters

• Machinecategory
• Server

• Memory

• ECC
• Yes

• Internal memory type
• DDR3-SDRAM

• Memory clock speed
• 1600 MHz

• Memory Installed
• 8 GB

• Memory layout (slots x size)
• 1 x 8 GB

• Memory Slot Support
• 786432 MB
  768 GB

• Memory slots
• 24x DIMM

• Network

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet interface type
• Gigabit Ethernet

• Ethernet LAN
• Yes

• LAN controller
• Broadcom BCM5719

• Other features

• Built-in display
• Yes

• Display
• LCD

• Performance

• Performance management
• IPMI 2.0, Dell OpenManage

• Remote administration
• iDRAC Enterprise

• Trusted Platform Module (TPM)
• Yes

• Ports & interfaces

• Ethernet LAN (RJ-45) ports
• 4

• Serial ports quantity
• 1

• USB 2.0 ports quantity
• 8

• VGA (D-Sub) ports quantity
• 1

• Power

• Number of main power supplies
• 1

• Number of redundant power supplies installed
• 1

• Power supply
• 750 W

• Redundant power supply (RPS) support
• Yes

• Processor

• Bus type
• QPI

• Compatible processor series
• Intel® Xeon®

• Conflict-Free processor
• No

• CPU multiplier (bus/core ratio)
• 25

• ECC supported by processor
• Yes

• Embedded options available
• Yes

• Execute Disable Bit
• Yes

• FSB Parity
• No

• Graphics & IMC lithography
• 32 nm

• Idle States
• Yes

• Intelligent Platform Management Interface (IPMI) support
• Yes

• Maximum internal memory supported by processor
• 750 GB

• Maximum number of PCI Express lanes
• 40

• Maximum number of SMP processors
• 2

• Memory bandwidth supported by processor (max)
• 42.6 GB/s

• Memory channels supported by processor
• Quad

• Memory clock speeds supported by processor
• 800,1066,1333 MHz

• Memory types supported by processor
• DDR3-SDRAM

• Motherboard chipset
• Intel® C602

• Number of Cores
• 6

• Number of processors installed
• 1

• Number of QPI links
• 2

• PCI Express configurations
• x4, x8, x16

• Physical Address Extension (PAE)
• 46 bit

• Processor
• E5-2620

• Processor boost frequency
• 2.5 GHz

• Processor cache
• 15 MB

• Processor cache type
• Smart Cache

• Processor codename
• Sandy Bridge EP

• Processor family
• Intel® Xeon® E5 Family

• Processor frequency
• 2 GHz

• Processor lithography
• 32 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor package size
• 52.5 x 45.0 mm

• Processor series
• Intel Xeon E5-2600

• Processor socket
• LGA 2011 (Socket R)

• Processor threads
• 12

• Scalability
• 2S

• Stepping
• C2

• Supported instruction sets
• AVX

• System bus rate
• 7.2 GT/s

• Tcase
• 77.4 °C

• Thermal Design Power (TDP)
• 95 W

• Thermal Monitoring Technologies
• Yes

• Processor special features

• CPU configuration (max)
• 2

• Enhanced Intel SpeedStep Technology
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• No

• Intel Demand Based Switching
• Yes

• Intel Dual Display Capable Technology
• No

• Intel Enhanced Halt State
• Yes

• Intel Fast Memory Access
• No

• Intel FDI Technology
• No

• Intel Flex Memory Access
• No

• Intel Identity Protection Technology version
• 0.00

• Intel Rapid Storage Technology
• No

• Intel Secure Key Technology version
• 1.00

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI version
• 0.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Anti-Theft Technology (Intel® AT)
• No

• Intel® Clear Video HD Technology (Intel® CVT HD)
• No

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• No

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• No

• Intel® Insider™
• No

• Intel® InTru™ 3D Technology
• No

• Intel® My WiFi Technology (Intel® MWT)
• No

• Intel® Quick Sync Video Technology
• No

• Intel® Secure Key
• Yes

• Intel® Turbo Boost Technology
• 1.0

• Intel® Wireless Display (Intel® WiDi)
• No

• Processor ARK ID
• 64594

• Software

• Compatible operating systems
• Microsoft Windows Server 2012 Microsoft Windows Server 2008 R2 SP1, (x64) Novell SUSE Linux Enterprise Server Red Hat Enterprise Linux Citrix XenServer VMware vSphere ESXi Red Hat Enterprise Virtualization

• Storage

• Internal drive bays
• 12

• Maximum storage capacity
• 48 TB

• Number of HDDs supported
• 12

• Optical drive type
• DVD-RW

• RAID levels
• 0, 1, 5, 6, 10, 50, 60

• RAID support
• Yes

• Supported HDD sizes
• 3.5"

• Supported storage drive interfaces
• Serial ATA

• Technical details

• Sustainability certificates
• ENERGY STAR
