• Certificates

• Certification
• CB, RoHS, WEEE, GS, CE, CSAc/us, FCC, ICES, NMB, VCCI, JIS, EAC, KC, CCC, RCM, BSMI

• Design

• Chassis type
• Rack (2U)

• Product colour
• Black, Stainless steel

• Rack mounting
• Yes

• Redundant fans support
• Yes

• Expansion slots

• PCI Express slots version
• 3.0

• PCI Express x16 (Gen 3.x) slots
• 3

• PCI Express x8 (Gen 3.x) slots
• 3

• Filters

• Machinecategory
• Server

• Graphics

• On-board graphics card model
• Not available

• Logistics data

• Harmonized System (HS) code
• 84714100

• Memory

• ECC
• Yes

• Internal memory type
• DDR4-SDRAM

• Memory clock speed
• 2933 MHz

• Memory Installed
• 16 GB

• Memory Slot Support
• 768 GB

• Memory slots
• 12x DIMM

• Network

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet interface type
• Gigabit Ethernet

• Ethernet LAN
• Yes

• Operational conditions

• Operating relative humidity (H-H)
• 10 - 85%

• Operating temperature (T-T)
• 5 - 45 °C

• Performance

• Noise level
• 36 dB

• Performance management
• IPMI 2.0

• Remote administration
• iRMC S5

• Ports & interfaces

• Ethernet LAN (RJ-45) ports
• 2

• USB 2.0 ports quantity
• 1

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 7

• VGA (D-Sub) ports quantity
• 1

• Power

• Number of redundant power supplies installed
• 1

• Power supply
• 800 W

• Power supply input frequency
• 50 - 60 Hz

• Redundant power supply (RPS) support
• Yes

• Processor

• Embedded options available
• Yes

• Execute Disable Bit
• Yes

• Intelligent Platform Management Interface (IPMI) support
• Yes

• Maximum internal memory supported by processor
• 1.02 TB

• Maximum number of PCI Express lanes
• 48

• Maximum number of SMP processors
• 2

• Memory clock speeds supported by processor
• 2400 MHz

• Memory types supported by processor
• DDR4-SDRAM

• Motherboard chipset
• Intel® C624

• Number of Cores
• 10

• Number of processors installed
• 1

• Processor
• 4210

• Processor boost frequency
• 3.2 GHz

• Processor cache
• 13.75 MB

• Processor codename
• Cascade Lake

• Processor family
• Intel Xeon Silver

• Processor frequency
• 2.2 GHz

• Processor generation
• 2nd Generation Intel® Xeon® Scalable

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor package size
• 76.0 x 56.5 mm

• Processor socket
• LGA 3647 (Socket P)

• Processor threads
• 20

• Scalability
• 2S

• Supported instruction sets
• AVX-512

• Tcase
• 78 °C

• Thermal Design Power (TDP)
• 85 W

• Processor special features

• Enhanced Intel SpeedStep Technology
• Yes

• Intel 64
• Yes

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• Yes

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Processor ARK ID
• 193384

• Software

• Compatible operating systems
• Windows Server 2019 Datacenter Windows Server 2019 Standard Windows Server 2019 Essentials Windows Server Datacenter, version 1809 Windows Server Standard, version 1809 Hyper-V Server 2016 Windows Server 2016 Datacenter Windows Server 2016 Standard Windows Server 2016 Essentials Windows Storage Server 2016 Standard Windows Server Datacenter, version 1709 VMware vSphere6.7 VMware vSphere 6.5 SUSE Linux Enterprise Server 12 Red Hat Enterprise Linux 8 Red Hat Enterprise Linux 7 Univention Corporate Server 4

• Operating system installed
• No

• Storage

• HDD interface
• Serial ATA III, Serial Attached SCSI (SAS)

• HDD size
• 2.5"

• Hot-Plug support
• Yes

• Hot-swap
• Yes

• Number of HDDs supported
• 8

• Optical drive type
• No

• RAID support
• Yes

• Supported HDD sizes
• 2.5"

• Weight & dimensions

• Depth
• 770 mm

• Height
• 86.6 mm

• Weight
• 25 kg

• Width
• 482.4 mm
