• Audio

• Audio system
• DTS Sound

• Built-in microphone
• Yes

• Battery

• Battery capacity
• 75 Wh

• Battery technology
• Lithium-Ion (Li-Ion)

• Number of battery cells
• 8

• Camera

• Front camera
• Yes

• Front camera resolution
• 1280 x 720 pixels

• Design

• Country of origin
• China

• Form factor
• Clamshell

• Product colour
• Black

• Product type
• Mobile workstation

• Display

• HD type
• Full HD

• LED backlight
• Yes

• Native aspect ratio
• 16:9

• Screen Resolution
• 1920 x 1080 pixels

• Screen Size
• 43.9 cm (17.3")

• Touchscreen
• No

• Filters

• Machinecategory
• Mobile workstation

• Graphics

• Discrete graphics card
• Yes

• Discrete graphics card memory
• 4 GB

• Discrete graphics card model
• NVIDIA® Quadro® K3100M

• Discrete graphics memory type
• GDDR5

• Maximum on-board graphics card memory
• 1.74 GB

• On-board graphics card
• Yes

• On-board graphics card base frequency
• 400 MHz

• On-board graphics card DirectX version
• 11.2/12

• On-board graphics card dynamic frequency (max)
• 1150 MHz

• On-board graphics card family
• Intel® HD Graphics

• On-board graphics card ID
• 0x416

• On-board graphics card model
• Intel® HD Graphics 4600

• Keyboard

• Full-size keyboard
• Yes

• Keyboard backlit
• Yes

• Numeric keypad
• Yes

• Memory

• Internal memory type
• DDR3L-SDRAM

• Memory clock speed
• 1600 MHz

• Memory Installed
• 8 GB

• Memory layout (slots x size)
• 2 x 4 GB

• Memory slots
• 4x SO-DIMM

• Network

• Bluetooth
• Yes

• Bluetooth version
• 4.0

• Ethernet LAN
• Yes

• Ethernet LAN data rates
• 10,100,1000 Mbit/s

• Top Wi-Fi standard
• Wi-Fi 5 (802.11ac)

• Wi-Fi
• Yes

• Wi-Fi standards
• Wi-Fi 5 (802.11ac)

• Operational conditions

• Operating relative humidity (H-H)
• 0 - 90%

• Operating temperature (T-T)
• 10 - 35 °C

• Ports & interfaces

• CardBus PCMCIA slot type
• No

• Charging port type
• DC-in jack

• Combo headphone/mic port
• Yes

• DisplayPorts quantity
• 1

• Docking connector
• Yes

• DVI port
• No

• Ethernet LAN (RJ-45) ports
• 1

• ExpressCard slot
• Yes

• Microphone in
• No

• S/PDIF out port
• No

• SmartCard slot
• Yes

• Thunderbolt 2 ports quantity
• 1

• USB 2.0 ports quantity
• 1

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 3

• VGA (D-Sub) ports quantity
• 1

• Power

• AC adapter power
• 200 W

• Processor

• Bus type
• DMI

• ECC supported by processor
• No

• FSB Parity
• No

• Maximum number of PCI Express lanes
• 16

• Motherboard chipset
• Intel® QM87

• Number of Cores
• 4

• PCI Express configurations
• 1x16, 2x8, 1x8+2x4

• PCI Express slots version
• 3.0

• Processor
• i7-4710MQ

• Processor boost frequency
• 3.5 GHz

• Processor cache
• 6 MB

• Processor cache type
• Smart Cache

• Processor codename
• Haswell

• Processor family
• Intel® Core™ i7

• Processor frequency
• 2.5 GHz

• Processor generation
• 4th gen Intel® Core™ i7

• Processor lithography
• 22 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor series
• Intel Core i7-4700 Mobile series

• Processor socket
• PGA946

• Processor threads
• 8

• Stepping
• C0

• System bus rate
• 5 GT/s

• Thermal Design Power (TDP)
• 47 W

• Tjunction
• 100 °C

• Processor special features

• Conflict-Free processor
• Yes

• CPU configuration (max)
• 1

• Embedded options available
• No

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Idle States
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• No

• Intel Demand Based Switching
• No

• Intel Dual Display Capable Technology
• No

• Intel Enhanced Halt State
• Yes

• Intel Fast Memory Access
• No

• Intel FDI Technology
• Yes

• Intel Flex Memory Access
• No

• Intel Identity Protection Technology version
• 1.00

• Intel Rapid Storage Technology
• No

• Intel Secure Key Technology version
• 1.00

• Intel Trusted Execution Technology
• No

• Intel TSX-NI
• No

• Intel TSX-NI version
• 0.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• No

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Anti-Theft Technology (Intel® AT)
• Yes

• Intel® Clear Video HD Technology (Intel® CVT HD)
• Yes

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• No

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• Yes

• Intel® Insider™
• Yes

• Intel® InTru™ 3D Technology
• Yes

• Intel® My WiFi Technology (Intel® MWT)
• No

• Intel® Quick Sync Video Technology
• Yes

• Intel® Secure Key
• Yes

• Intel® Smart Cache
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Intel® Wireless Display (Intel® WiDi)
• Yes

• Processor ARK ID
• 78931

• Processor code
• SR1PQ

• Processor package size
• 37.5 x 32 x 1.6 mm

• Supported instruction sets
• AVX 2.0, SSE4.1, SSE4.2

• Thermal Monitoring Technologies
• Yes

• Security

• Cable lock slot
• Yes

• Software

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 7 Professional

• Storage

• Card reader integrated
• Yes

• Compatible memory cards
• SD, SDHC, SDXC

• Number of SSDs installed
• 1

• Optical drive type
• DVD Super Multi DL

• SSD capacity
• 256 GB

• Storage Capacity
• 256 GB

• Storage type
• SSD

• Total SSDs capacity
• 256 GB

• Sustainability

• Sustainability certificates
• ENERGY STAR

• Weight & dimensions

• Depth
• 272 mm

• Height
• 34 mm

• Weight
• 3.41 kg

• Width
• 416 mm
