Neomounts WL40S-840BL12 TV mount wall 32-55" - full motion - fast installation

Roll over image to zoom inClick to Open expanded view

Neomounts WL40S-840BL12 TV mount wall 32-55" - full motion - fast installation

Name: Neomounts WL40S-840BL12 TV mount wall 32-55" - full motion - fast installation
Brand: Neomounts
SKU: WL40S-840BL12

SKU: WL40S-840BL12

Log In to View Pricing

Currently out of Stock

Neomounts WL40S-840BL12 TV mount wall 32-55" - full motion - fast installation, 100 x 100 mm, 200 x 200 mm, -2 - 12°, 0 - 30°, Steel, Black

Currently out of Stock

hypertec

Safety information (Download)

WL40S-840BL12_Greensheet_EN (Download)

Product manual (Download)

Datasheets (Download)

Add to compare

Product Properties

Manufacturer
Neomounts

Warranty
5 Years

SKU
WL40S-840BL12

EAN
8717371448806

Design

Housing material
Steel

Product colour
Black

Ergonomics

Angle of rotation
6°

Cable management
Yes

Distance to the wall (max)
34.5 cm

Distance to the wall (min)
4.9 cm

Height adjustment
No

Pivot angle
-3 - 3°

Rotating
Yes

Swivel angle
30°

Swivel angle range
0 - 30°

Swivelling
Yes

Tilt adjustment
Yes

Tilt angle range
-2 - 12°

Type
Full motion

Logistics data

Harmonized System (HS) code
7326909890

Master (outer) case gross weight
16.9 kg

Master (outer) case height
352 mm

Master (outer) case length
267 mm

Master (outer) case net weight
13 kg

Master (outer) case width
530 mm

Products per master (outer) case
4 pc(s)

Products per pallet (EU)
96 pc(s)

Mounting

Maximum screen size
139.7 cm (55")

Maximum VESA mount
200 x 200 mm

Maximum weight capacity
40 kg

Maximum weight capacity (per display)
40 kg

Minimum screen size
81.3 cm (32")

Minimum VESA mount
100 x 100 mm

Mounting type
Wall

Number of displays supported
1

Panel mounting interface
200 x 200 mm

Packaging content

Hex key included
Yes

Mounting kit
Yes

Number of wrenches included
1

Packaging data

Package depth
332 mm

Package height
62 mm

Package weight
4.1 kg

Package width
511 mm

Technical details

Country of origin
China

Lockable
Not lockable

Package net weight
4.1 kg

Quantity per pack
1 pc(s)

Weight & dimensions

Depth
49 mm

Height
271 mm

Weight
2.95 kg

Width
252 mm

Description

Neomounts WL40S-840BL12 TV mount wall 32-55" - full motion - fast installation. Maximum weight capacity: 40 kg, Minimum screen size: 81.3 cm (32"), Maximum screen size: 139.7 cm (55"), Minimum VESA mount: 100 x 100 mm, Maximum VESA mount: 200 x 200 mm. Tilt angle range: -2 - 12°, Swivel angle range: 0 - 30°, Angle of rotation: 6°, Distance to the wall (min): 4.9 cm, Distance to the wall (max): 34.5 cm. Product colour: Black

Maximum weight capacity: 40 kg
Minimum screen size: 81.3 cm (32") Maximum screen size: 139.7 cm (55") Wall
Minimum VESA mount: 100 x 100 mm Maximum VESA mount: 200 x 200 mm
Number of displays supported: 1
Tilt adjustment Rotating
Cable management
Steel Black
