• Design

• Chassis type
• Rack

• Rack mounting
• Yes

• Rack rails
• Yes

• Expansion slots

• PCI Express slots version
• 3.0

• PCI Express x16 slots
• 1

• PCI Express x8 slots
• 3

• Filters

• Machinecategory
• Server

• Graphics

• On-board graphics card model
• Not available

• Memory

• ECC
• Yes

• Internal memory type
• DDR4-SDRAM

• Memory clock speed
• 2133 MHz

• Memory Installed
• 8 GB

• Memory layout (slots x size)
• 1 x 8 GB

• Memory Slot Support
• 768 GB

• Memory slots
• 24

• Network

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet interface type
• Fast Ethernet, Gigabit Ethernet

• Ethernet LAN
• Yes

• LAN controller
• Broadcom 5720

• Wake-on-LAN ready
• Yes

• Other features

• Dell E-Value Code
• PER7301

• Ports & interfaces

• Ethernet LAN (RJ-45) ports
• 4

• Serial ports quantity
• 1

• USB 2.0 ports quantity
• 2

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 2

• VGA (D-Sub) ports quantity
• 2

• Processor

• Bus type
• QPI

• Conflict-Free processor
• Yes

• ECC supported by processor
• Yes

• Embedded options available
• Yes

• Execute Disable Bit
• Yes

• FSB Parity
• No

• Idle States
• Yes

• Maximum internal memory supported by processor
• 1.54 TB

• Maximum number of PCI Express lanes
• 40

• Maximum number of SMP processors
• 2

• Memory bandwidth supported by processor (max)
• 59.7 GB/s

• Memory channels supported by processor
• Quad

• Memory clock speeds supported by processor
• 1600,1866 MHz

• Memory types supported by processor
• DDR4-SDRAM

• Motherboard chipset
• Intel C610

• Number of Cores
• 8

• Number of processors installed
• 1

• Number of QPI links
• 2

• PCI Express configurations
• 1x4, 1x8, 1x16

• Physical Address Extension (PAE)
• 46 bit
  Yes

• Processor
• E5-2609V4

• Processor cache
• 20 MB

• Processor cache type
• Smart Cache

• Processor code
• SR2P1

• Processor codename
• Broadwell

• Processor family
• Intel® Xeon® E5 v4

• Processor frequency
• 1.7 GHz

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor package size
• 45 x 52.5 mm

• Processor series
• Intel Xeon E5-2600 v4

• Processor socket
• LGA 2011-v3

• Processor threads
• 8

• Scalability
• 2S

• Stepping
• R0

• Supported instruction sets
• AVX 2.0

• System bus rate
• 6.4 GT/s

• Tcase
• 74 °C

• Thermal Design Power (TDP)
• 85 W

• Thermal Monitoring Technologies
• Yes

• Processor special features

• CPU configuration (max)
• 2

• Enhanced Intel SpeedStep Technology
• Yes

• Intel 64
• Yes

• Intel Demand Based Switching
• Yes

• Intel Enhanced Halt State
• Yes

• Intel Flex Memory Access
• No

• Intel Identity Protection Technology version
• 0.00

• Intel Secure Key Technology version
• 1.00

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• Yes

• Intel TSX-NI version
• 1.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• No

• Intel® Identity Protection Technology (Intel® IPT)
• No

• Intel® OS Guard
• Yes

• Intel® Secure Key
• Yes

• Intel® Turbo Boost Technology
• No

• Processor ARK ID
• 92990

• Software

• Compatible operating systems
• Microsoft Windows Server 2008/2012 SP2, x86/x64 (x64 includes Hyper-VTM ) Microsoft Windows Server 2008/2012 R2, x64 (includes Hyper-VTM v2) Microsoft Windows HPC Server 2008 Novell SUSE Linux Enterprise Server Red Hat Enterprise Linux VMware ESX

• Operating system installed
• No

• Storage

• Card reader integrated
• Yes

• Compatible memory cards
• SD

• HDD capacity
• 1 TB

• HDD interface
• Serial ATA

• HDD size
• 3.5"

• Hot-Plug support
• Yes

• Maximum storage capacity
• 64 TB

• Number of HDDs installed
• 1

• Number of HDDs supported
• 8

• Optical drive type
• No

• RAID levels
• 1

• RAID support
• Yes

• Storage Capacity
• 1 TB

• Supported HDD sizes
• 3.5"

• Supported storage drive interfaces
• Serial ATA

• Weight & dimensions

• Depth
• 684 mm

• Height
• 87.3 mm

• Width
• 440 mm
