• Certificates

• Certification
• CB, RoHS, WEEE, GS, CE, CSAc/us, ULc/us, FCC Class A, VCCI:V3 Class A + JIS 61000-3-2, GOST, KC, CCC, C-Tick, BSMI

• Design

• Chassis type
• Rack (1U)

• Product colour
• Black, Grey

• Rack mounting
• Yes

• Expansion slots

• PCI Express slots version
• 3.0

• PCI Express x4 (Gen 3.x) slots
• 1

• PCI Express x8 (Gen 3.x) slots
• 2

• Filters

• Machinecategory
• Server

• Graphics

• On-board graphics card model
• Not available

• Logistics data

• Harmonized System (HS) code
• 84714100

• Memory

• ECC
• Yes

• Internal memory type
• DDR4-SDRAM

• Memory clock speed
• 2666 MHz

• Memory Installed
• 16 GB

• Memory Slot Support
• 128 GB

• Memory slots
• 4

• Network

• Cabling technology
• 10/100/1000Base-T(X)

• Ethernet interface type
• Gigabit Ethernet

• Ethernet LAN
• Yes

• LAN controller
• Intel I210

• Operational conditions

• Operating relative humidity (H-H)
• 10 - 85%

• Operating temperature (T-T)
• 5 - 45 °C

• Ports & interfaces

• Ethernet LAN (RJ-45) ports
• 2

• USB 2.0 ports quantity
• 2

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 4

• VGA (D-Sub) ports quantity
• 1

• Power

• Number of redundant power supplies installed
• 1

• Power supply
• 450 W

• Processor

• Embedded options available
• No

• Execute Disable Bit
• Yes

• Idle States
• Yes

• Maximum internal memory supported by processor
• 128 GB

• Maximum number of PCI Express lanes
• 16

• Memory clock speeds supported by processor
• 2666 MHz

• Memory types supported by processor
• DDR4-SDRAM

• Number of Cores
• 4

• Number of processors installed
• 1

• PCI Express configurations
• 1x16, 2x8, 1x8+2x4

• Processor
• E-2224

• Processor boost frequency
• 4.6 GHz

• Processor cache
• 8 MB

• Processor codename
• Coffee Lake

• Processor family
• Intel Xeon E

• Processor frequency
• 3.4 GHz

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor package size
• 37.5 x 37.5 mm

• Processor socket
• LGA 1151 (Socket H4)

• Processor threads
• 4

• Scalability
• 1S

• Supported instruction sets
• SSE4.1, SSE4.2, AVX 2.0

• Tcase
• 69.3 °C

• Thermal Design Power (TDP)
• 71 W

• Thermal Monitoring Technologies
• Yes

• Tjunction
• 100 °C

• Processor special features

• CPU configuration (max)
• 1

• Enhanced Intel SpeedStep Technology
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• No

• Intel Software Guard Extensions (Intel SGX)
• Yes

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• Yes

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Clear Video HD Technology (Intel® CVT HD)
• No

• Intel® Hyper Threading Technology (Intel® HT Technology)
• No

• Intel® InTru™ 3D Technology
• No

• Intel® OS Guard
• Yes

• Intel® Quick Sync Video Technology
• No

• Intel® Secure Key
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Processor ARK ID
• 191036

• Software

• Compatible operating systems
• Windows Server 2019 Datacenter, Windows Server 2019 Standard, Windows Server 2019 Essentials, Windows Server Datacenter, version 1809, Windows Server Standard, version 1809, Hyper-V Server 2016, Windows Server 2016 Datacenter, Windows Server 2016 Standard, Windows Server 2016 Essentials, Windows Storage Server 2016 Standard, Windows Server Datacenter, version 1709, VMware vSphere 6.5, VMware vSphere 6.7, SUSE Linux Enterprise Server 12, Red Hat Enterprise Linux 7

• Storage

• HDD interface
• Serial ATA III, Serial Attached SCSI (SAS)

• HDD size
• 2.5"

• Number of HDDs supported
• 4

• RAID levels
• 0, 1, 10

• RAID support
• Yes

• Supported HDD sizes
• 2.5,3.5"

• Weight & dimensions

• Depth
• 572 mm

• Height
• 42.8 mm

• Weight
• 13 kg

• Width
• 482.6 mm
