• Design

• Chassis type
• Rack (2U)

• Expansion slots

• PCI Express slots version
• 3.0

• PCI Express x8 (Gen 3.x) slots
• 8

• Filters

• Machinecategory
• Server

• Graphics

• On-board graphics card model
• Not available

• Memory

• ECC
• Yes

• Internal memory type
• DDR4-SDRAM

• Memory clock speed
• 2133 MHz

• Memory Installed
• 16 GB

• Memory Slot Support
• 768 GB

• Memory slots
• 24

• Operational conditions

• Operating temperature (T-T)
• 5 - 45 °C

• Storage temperature (T-T)
• -10 - 60 °C

• Other features

• Flash memory
• 2048 MB

• Performance

• Trusted Platform Module (TPM)
• No

• Ports & interfaces

• DisplayPorts quantity
• 1

• Ethernet LAN (RJ-45) ports
• 4

• Serial ports quantity
• 1

• USB 2.0 ports quantity
• 4

• Power

• Number of redundant power supplies installed
• 1

• Power supply
• 750 W

• Redundant power supply (RPS) support
• Yes

• Processor

• Bus type
• QPI

• Configurable TDP-down
• 85 W

• Conflict-Free processor
• No

• ECC supported by processor
• Yes

• Embedded options available
• Yes

• Execute Disable Bit
• Yes

• FSB Parity
• No

• Idle States
• Yes

• Maximum internal memory supported by processor
• 768 GB

• Maximum number of PCI Express lanes
• 40

• Memory bandwidth supported by processor (max)
• 59 GB/s

• Memory channels supported by processor
• Quad

• Memory clock speeds supported by processor
• 1600,1866 MHz

• Memory types supported by processor
• DDR4-SDRAM

• Number of Cores
• 6

• Number of processors installed
• 1

• Number of QPI links
• 2

• PCI Express configurations
• x4, x8, x16

• Physical Address Extension (PAE)
• 46 bit
  Yes

• Processor
• E5-2620V3

• Processor boost frequency
• 3.2 GHz

• Processor cache
• 15 MB

• Processor cache type
• Smart Cache

• Processor code
• SR207

• Processor codename
• Haswell

• Processor family
• Intel Xeon E5 v3

• Processor frequency
• 2.4 GHz

• Processor lithography
• 22 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor package size
• 52.5 x 45 mm

• Processor series
• Intel Xeon E5-2600 v3

• Processor socket
• LGA 2011-v3

• Processor threads
• 12

• Scalability
• 2S

• Stepping
• R2

• Supported instruction sets
• AVX

• System bus rate
• 8 GT/s

• Tcase
• 72.6 °C

• Thermal Design Power (TDP)
• 85 W

• Thermal Monitoring Technologies
• Yes

• Processor special features

• CPU configuration (max)
• 2

• Enhanced Intel SpeedStep Technology
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• No

• Intel Demand Based Switching
• Yes

• Intel Dual Display Capable Technology
• No

• Intel Enhanced Halt State
• Yes

• Intel Fast Memory Access
• No

• Intel FDI Technology
• No

• Intel Flex Memory Access
• No

• Intel Identity Protection Technology version
• 0.00

• Intel On-Demand Power Redundancy Technology
• Yes

• Intel Rapid Storage Technology
• No

• Intel Secure Key Technology version
• 1.00

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• No

• Intel TSX-NI version
• 0.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Anti-Theft Technology (Intel® AT)
• No

• Intel® Clear Video HD Technology (Intel® CVT HD)
• No

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• No

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• No

• Intel® Insider™
• No

• Intel® InTru™ 3D Technology
• No

• Intel® My WiFi Technology (Intel® MWT)
• No

• Intel® OS Guard
• Yes

• Intel® Quick Sync Video Technology
• No

• Intel® Secure Key
• Yes

• Intel® Smart Cache
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Intel® Wireless Display (Intel® WiDi)
• No

• Processor ARK ID
• 83352

• Software

• Compatible operating systems
• Microsoft Windows Server 2012 R2 (Including Hyper-V), Microsoft Windows Server 2012 (Including Hyper-V), Microsoft Windows Server 2008 R2 SP1 (Including Hyper-V), SUSE Linux Enterprise Server, Red Hat Enterprise Linux Server, VMware vSphere ESXi

• Operating system installed
• No

• Storage

• HDD interface
• Serial ATA III

• HDD size
• 2.5"

• Maximum storage capacity
• 74 TB

• Number of HDDs installed
• 2

• Optical drive type
• DVD±RW

• RAID support
• Yes

• Storage Capacity
• 600 GB

• Technical details

• Number of 2.5" bays
• 8

• Weight & dimensions

• Depth
• 762 mm

• Height
• 87 mm

• Weight
• 15.9 kg

• Width
• 482.6 mm
