Name: Chassis 2x2.5", Intel Xeon E5-2630 v4 (25M Cache, 2.20 GHz), 16GB DDR4 2133MHz, Broadcom 5720, iDRAC8 Exp, PERC H730P
Brand: Dell
SKU: 630-0992

DELL PowerEdge FC630 server 0 GB Rack (1U) Intel® Xeon® E5 v4 E5-2630V4 2.2 GHz 16 GB DDR4-SDRAM

Roll over image to zoom inClick to Open expanded view

Product Properties

Manufacturer
Dell

Device type
Server

Design

Chassis type
Rack (1U)

Expansion slots

PCI Express slots version
3.0

PCI Express x8 (Gen 3.x) slots
2

Filters

Machinecategory
Server

Graphics

Maximum graphics card memory
16 MB

Memory

Buffered memory type
Registered (buffered)

Internal memory type
DDR4-SDRAM

Memory clock speed
2133 MHz

Memory Installed
16 GB

Memory Slot Support
768 GB

Memory slots
24x DIMM

Network

Cabling technology
10/100/1000Base-T(X)

Ethernet interface type
Gigabit Ethernet

Ethernet LAN
Yes

LAN controller
Broadcom 5720

Other features

Dell E-Value Code
PEFC630a

Graphics card
G200

Graphics card family
Matrox

Power

Redundant power supply (RPS) support
Yes

Processor

Bus type
QPI

Conflict-Free processor
Yes

ECC supported by processor
Yes

Embedded options available
No

Execute Disable Bit
Yes

Idle States
Yes

Maximum internal memory supported by processor
1.54 TB

Maximum number of PCI Express lanes
40

Memory bandwidth supported by processor (max)
68.3 GB/s

Memory channels supported by processor
Quad

Memory clock speeds supported by processor
1600,1866,2133 MHz

Memory types supported by processor
DDR4-SDRAM

Number of Cores
10

Number of processors installed
1

Number of QPI links
2

Physical Address Extension (PAE)
46 bit

Yes

Processor
E5-2630V4

Processor boost frequency
3.1 GHz

Processor cache
25 MB

Processor cache type
Smart Cache

Processor code
SR2R7

Processor codename
Broadwell

Processor family
Intel® Xeon® E5 v4

Processor frequency
2.2 GHz

Processor lithography
14 nm

Processor manufacturer
Intel

Processor operating modes
64-bit

Processor package size
45 x 52.5 mm

Processor series
Intel Xeon E5-2600 v4

Processor socket
LGA 2011-v3

Processor threads
20

Scalability
2S

Stepping
R0

Supported instruction sets
AVX 2.0

System bus rate
8 GT/s

Tcase
74 °C

Thermal Design Power (TDP)
85 W

Thermal Monitoring Technologies
Yes

Processor special features

CPU configuration (max)
2

Enhanced Intel SpeedStep Technology
Yes

Intel 64
Yes

Intel Demand Based Switching
Yes

Intel Enhanced Halt State
Yes

Intel Flex Memory Access
No

Intel Identity Protection Technology version
0.00

Intel Secure Key Technology version
1.00

Intel Trusted Execution Technology
Yes

Intel TSX-NI
Yes

Intel TSX-NI version
1.00

Intel Virtualization Technology (VT-x)
Yes

Intel Virtualization Technology for Directed I/O (VT-d)
Yes

Intel VT-x with Extended Page Tables (EPT)
Yes

Intel® AES New Instructions (Intel® AES-NI)
Yes

Intel® Hyper Threading Technology (Intel® HT Technology)
Yes

Intel® Identity Protection Technology (Intel® IPT)
No

Intel® OS Guard
Yes

Intel® Secure Key
Yes

Intel® Turbo Boost Technology
2.0

Processor ARK ID
92981

Software

Compatible operating systems
Microsoft Windows Server 2008 R2 SP1, 2012, 2012 R2 Novell SUSE Linux Enterprise Server Red Hat Enterprise Linux

Operating system installed
No

Storage

Number of HDDs supported
2

Optical drive type
No

RAID levels
1, 5, 6, 10

RAID support
Yes

Supported HDD sizes
2.5"

Supported storage drive interfaces
Serial ATA

Weight & dimensions

Depth
50.8 mm

Height
40.3 mm

Width
210.9 mm

Memory

Internal memory type
DDR4-SDRAM

Memory clock speed
2133 MHz

Memory Installed
16 GB

Memory Slot Support
768 GB

Memory slots
24x DIMM

Processor

Processor
E5-2630V4
