• Audio

• Audio system
• HD

• Built-in microphone
• Yes

• Number of built-in speakers
• 2

• Battery

• Battery capacity
• 60 Wh

• Battery technology
• Lithium-Ion (Li-Ion)

• Battery voltage
• 11.1 V

• Number of battery cells
• 6

• Camera

• Front camera
• Yes

• Front camera resolution
• 1280 x 720 pixels

• Design

• Form factor
• Clamshell

• Market positioning
• Business

• Product colour
• Black, Silver

• Product type
• Mobile workstation

• Display

• Display brightness
• 200 cd/m²

• Display surface
• Matt

• HD type
• HD

• LED backlight
• Yes

• Native aspect ratio
• 16:9

• Pixel pitch
• 0.252 x 0.252 mm

• Screen Resolution
• 1366 x 768 pixels

• Screen Size
• 39.6 cm (15.6")

• Touchscreen
• No

• Filters

• Machinecategory
• Mobile workstation

• Graphics

• CUDA
• No

• Discrete graphics card
• Yes

• Discrete graphics card memory
• 2 GB

• Discrete graphics card model
• AMD FirePro W4170M

• Discrete graphics memory type
• GDDR5

• Graphics card Open GL support
• Yes

• Maximum on-board graphics card memory
• 1.74 GB

• Number of discrete graphics cards installed
• 1

• Number of discrete graphics cards supported
• 1

• NVIDIA G-SYNC
• No

• NVIDIA GameWorks VR
• No

• On-board graphics card
• Yes

• On-board graphics card base frequency
• 400 MHz

• On-board graphics card DirectX version
• 11.1

• On-board graphics card dynamic frequency (max)
• 1150 MHz

• On-board graphics card family
• Intel® HD Graphics

• On-board graphics card ID
• 0x416

• On-board graphics card model
• Intel® HD Graphics 4600

• Keyboard

• Full-size keyboard
• Yes

• Numeric keypad
• Yes

• Pointing device
• Touchpad

• Windows keys
• Yes

• Memory

• Internal memory type
• DDR3L-SDRAM

• Memory clock speed
• 1600 MHz

• Memory form factor
• SO-DIMM

• Memory Installed
• 8 GB

• Memory layout (slots x size)
• 2 x 4 GB

• Memory Slot Support
• 16 GB

• Memory slots
• 2x SO-DIMM

• Network

• Bluetooth
• Yes

• Bluetooth Low Energy (BLE)
• Yes

• Bluetooth version
• 4.0

• Ethernet LAN
• Yes

• Ethernet LAN data rates
• 10,100,1000 Mbit/s

• Wi-Fi
• Yes

• Wi-Fi standards
• 802.11a, Wi-Fi 5 (802.11ac), 802.11g, 802.11b, Wi-Fi 4 (802.11n)

• Operational conditions

• Non-operating altitude
• -15.24 - 10668 m

• Operating altitude
• -15.2 - 3048 m

• Operating relative humidity (H-H)
• 10 - 90%

• Operating temperature (T-T)
• 0 - 35 °C

• Storage relative humidity (H-H)
• 5 - 95%

• Storage temperature (T-T)
• -40 - 65 °C

• Other features

• 3D
• No

• AC adapter included
• Yes

• Disc types supported
• DVD, CD

• Intel® Virtualization Technology (Intel® VT)
• VT-x

• Maximum internal memory (64-bit)
• 16 GB

• Packaging content

• Manual
• Yes

• Power cord included
• Yes

• Quick start guide
• Yes

• Warranty card
• Yes

• Ports & interfaces

• CardBus PCMCIA slot type
• No

• Charging port type
• DC-in jack

• Combo headphone/mic port
• Yes

• Docking connector
• Yes

• DVI port
• No

• Ethernet LAN (RJ-45) ports
• 1

• HDMI ports
• 1

• Microphone in
• No

• S/PDIF out port
• No

• SmartCard slot
• Yes

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 4

• VGA (D-Sub) ports quantity
• 1

• Power

• AC adapter frequency
• 50 - 60 Hz

• AC adapter input voltage
• 100 - 240 V

• AC adapter output current
• 6.7 A

• AC adapter output voltage
• 19.5 V

• AC adapter power
• 130 W

• Processor

• Bus type
• DMI

• ECC supported by processor
• No

• FSB Parity
• No

• Maximum number of PCI Express lanes
• 16

• Motherboard chipset
• Intel® QM87

• Number of Cores
• 2

• PCI Express configurations
• 1x16, 2x8, 1x8+2x4

• PCI Express slots version
• 3.0

• Processor
• i5-4210M

• Processor boost frequency
• 3.2 GHz

• Processor cache
• 3 MB

• Processor cache type
• Smart Cache

• Processor codename
• Haswell

• Processor family
• Intel® Core™ i5

• Processor frequency
• 2.6 GHz

• Processor generation
• 4th gen Intel® Core™ i5

• Processor lithography
• 22 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor series
• Intel Core i5-4200 Mobile series

• Processor socket
• PGA946

• Processor threads
• 4

• Stepping
• C0

• System bus rate
• 5 GT/s

• Thermal Design Power (TDP)
• 37 W

• Tjunction
• 100 °C

• Processor special features

• Conflict-Free processor
• Yes

• CPU configuration (max)
• 1

• Embedded options available
• No

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Idle States
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• No

• Intel Demand Based Switching
• No

• Intel Dual Display Capable Technology
• No

• Intel Enhanced Halt State
• No

• Intel Fast Memory Access
• No

• Intel FDI Technology
• No

• Intel Flex Memory Access
• No

• Intel HD Graphics
• Yes

• Intel Identity Protection Technology version
• 1.00

• Intel Rapid Storage Technology
• No

• Intel Secure Key Technology version
• 1.00

• Intel Trusted Execution Technology
• No

• Intel TSX-NI
• No

• Intel TSX-NI version
• 0.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• No

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Anti-Theft Technology (Intel® AT)
• Yes

• Intel® Built-in Visuals Technology
• Yes

• Intel® Clear Video HD Technology (Intel® CVT HD)
• Yes

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• No

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• Yes

• Intel® Insider™
• Yes

• Intel® InTru™ 3D Technology
• Yes

• Intel® My WiFi Technology (Intel® MWT)
• No

• Intel® Quick Sync Video Technology
• Yes

• Intel® Secure Key
• Yes

• Intel® Smart Cache
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Intel® Wireless Display (Intel® WiDi)
• Yes

• Processor ARK ID
• 81012

• Processor code
• SR1L4

• Processor package size
• 37.5 x 37.5 x 4.7 mm

• Supported instruction sets
• AVX 2.0, SSE4.1, SSE4.2

• Thermal Monitoring Technologies
• Yes

• Security

• Cable lock slot
• Yes

• Cable lock slot type
• Kensington

• Password protection
• Yes

• Software

• Drivers included
• Yes

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 7 Professional

• Recovery operating system
• Windows 8.1

• Storage

• Card reader integrated
• Yes

• HDD capacity
• 500 GB

• HDD interface
• SATA III

• HDD size
• 2.5"

• HDD speed
• 7200 RPM

• Number of HDDs installed
• 1

• Optical drive type
• DVD Super Multi

• Storage Capacity
• 500 GB

• Storage type
• HDD

• Weight & dimensions

• Depth
• 250.5 mm

• Height
• 33.4 mm

• Weight
• 2.56 kg

• Width
• 379 mm
