• Audio

• Audio chip
• Realtek ALC255

• Built-in microphone
• Yes

• Battery

• Battery technology
• Lithium-Ion (Li-Ion)

• Number of battery cells
• 6

• Camera

• Front camera
• Yes

• Design

• Form factor
• Clamshell

• Product colour
• Grey

• Product type
• Laptop

• Display

• Display brightness
• 350 cd/m²

• Display surface
• Matt

• HD type
• Quad HD

• LED backlight
• Yes

• Panel type
• IGZO

• Screen Resolution
• 2560 x 1440 pixels

• Screen Size
• 33.8 cm (13.3")

• Touchscreen
• Yes

• Filters

• Machinecategory
• Notebook

• Graphics

• Discrete graphics card
• No

• Discrete graphics card model
• Not available

• Maximum on-board graphics card memory
• 32 GB

• On-board graphics card
• Yes

• On-board graphics card base frequency
• 300 MHz

• On-board graphics card DirectX version
• 12.0

• On-board graphics card dynamic frequency (max)
• 1050 MHz

• On-board graphics card ID
• 1916

• On-board graphics card model
• Intel® HD Graphics 520

• On-board graphics card OpenGL version
• 4.4

• Keyboard

• Keyboard backlit
• Yes

• Keyboard number of keys
• 85

• Numeric keypad
• No

• Pointing device
• Touchpad

• Memory

• Internal memory type
• DDR4-SDRAM

• Memory clock speed
• 2133 MHz

• Memory Installed
• 20 GB

• Memory Slot Support
• 20 GB

• Memory slots
• 1x SO-DIMM

• Network

• 4G standard
• LTE

• Bluetooth
• Yes

• Bluetooth version
• 4.1

• Ethernet LAN
• Yes

• Ethernet LAN data rates
• 10,100,1000 Mbit/s

• Mobile network connection
• Yes

• Network Type
• 4G

• Wi-Fi
• Yes

• Wi-Fi standards
• 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)

• Operational conditions

• Operating relative humidity (H-H)
• 20 - 85%

• Operating temperature (T-T)
• 5 - 35 °C

• Other features

• AC adapter included
• Yes

• Maximum internal memory (64-bit)
• 20 GB

• Packaging content

• Manual
• Yes

• Warranty card
• Yes

• Ports & interfaces

• Charging port type
• DC-in jack

• Combo headphone/mic port
• Yes

• Docking connector
• Yes

• DVI port
• No

• Ethernet LAN (RJ-45) ports
• 1

• HDMI ports
• 1

• SmartCard slot
• Yes

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 3

• VGA (D-Sub) ports quantity
• 1

• Power

• AC adapter frequency
• 50 - 60 Hz

• AC adapter input voltage
• 100 - 240 V

• Processor

• Bus type
• OPI

• Configurable TDP-down
• 7.5 W

• Configurable TDP-down frequency
• 0.8 GHz

• Configurable TDP-up
• 25 W

• Configurable TDP-up frequency
• 2.8 GHz

• ECC supported by processor
• No

• Maximum number of PCI Express lanes
• 12

• Number of Cores
• 2

• PCI Express configurations
• 1x4, 4x1

• PCI Express slots version
• 3.0

• Processor
• i7-6600U

• Processor boost frequency
• 3.4 GHz

• Processor cache
• 4 MB

• Processor cache type
• Smart Cache

• Processor codename
• Skylake

• Processor family
• Intel® Core™ i7

• Processor frequency
• 2.6 GHz

• Processor generation
• 6th gen Intel® Core™ i7

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor series
• Intel Core i7-6600 Mobile Series

• Processor socket
• LGA 1356 (Socket B2)

• Processor threads
• 4

• Stepping
• D1

• Thermal Design Power (TDP)
• 15 W

• Tjunction
• 100 °C

• Processor special features

• Conflict-Free processor
• Yes

• CPU configuration (max)
• 1

• Embedded options available
• Yes

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Graphics & IMC lithography
• 14 nm

• Idle States
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• Yes

• Intel Enhanced Halt State
• Yes

• Intel Flex Memory Access
• Yes

• Intel Identity Protection Technology version
• 1.00

• Intel Secure Key Technology version
• 1.00

• Intel Small Business Advantage (SBA) version
• 1.00

• Intel Smart Connect Technology
• Yes

• Intel Smart Response Technology version
• 1.00

• Intel Software Guard Extensions (Intel SGX)
• Yes

• Intel Stable Image Platform Program (SIPP)
• Yes

• Intel Stable Image Platform Program (SIPP) version
• 1.00

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• Yes

• Intel TSX-NI version
• 1.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Clear Video HD Technology (Intel® CVT HD)
• Yes

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• Yes

• Intel® Insider™
• Yes

• Intel® InTru™ 3D Technology
• Yes

• Intel® My WiFi Technology (Intel® MWT)
• Yes

• Intel® OS Guard
• Yes

• Intel® Quick Sync Video Technology
• Yes

• Intel® Secure Key
• Yes

• Intel® Small Business Advantage (Intel® SBA)
• Yes

• Intel® Smart Response Technology
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Intel® Wireless Display (Intel® WiDi)
• Yes

• Processor ARK ID
• 88192

• Processor code
• SR2F1

• Processor package size
• 42 x 24 mm

• Supported instruction sets
• SSE4.1, SSE4.2, AVX 2.0

• Thermal Monitoring Technologies
• Yes

• Security

• Palm vein scanner
• Yes

• Password protection
• Yes

• Password protection type
• BIOS, HDD, Supervisor, User

• Trusted Platform Module (TPM)
• Yes

• Software

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 10 Pro

• Storage

• Card reader integrated
• Yes

• Compatible memory cards
• SD, SDHC, SDXC

• Number of SSDs installed
• 1

• Optical drive type
• No

• SSD capacity
• 512 GB

• SSD interface
• M.2

• Storage Capacity
• 512 GB

• Storage type
• SSD

• Weight & dimensions

• Depth
• 214 mm

• Height
• 28.9 mm

• Weight
• 1.32 kg

• Width
• 316 mm
