• Audio

• Audio system
• HD

• Built-in microphone
• Yes

• Number of built-in speakers
• 2

• Battery

• Battery capacity
• 4400 mAh
  48 Wh

• Battery life (max)
• 6 h

• Battery technology
• Lithium-Ion (Li-Ion)

• Number of battery cells
• 6

• Camera

• Front camera
• Yes

• Design

• Form factor
• Clamshell

• Product colour
• Black

• Product type
• Laptop

• Display

• Contrast ratio (typical)
• 300:1

• Display brightness
• 200 cd/m²

• LED backlight
• Yes

• Native aspect ratio
• 16:9

• Screen Resolution
• 1366 x 768 pixels

• Screen Size
• 39.6 cm (15.6")

• Touchscreen
• No

• Filters

• Machinecategory
• Notebook

• Graphics

• Discrete graphics card
• No

• Discrete graphics card model
• Not available

• On-board graphics card
• Yes

• On-board graphics card base frequency
• 650 MHz

• On-board graphics card dynamic frequency (max)
• 1100 MHz

• On-board graphics card family
• Intel® HD Graphics

• On-board graphics card model
• Intel® HD Graphics

• Keyboard

• Keyboard number of keys
• 106

• Numeric keypad
• Yes

• Pointing device
• Touchpad

• Spill-resistant keyboard
• Yes

• Windows keys
• Yes

• Memory

• Internal memory type
• DDR3-SDRAM

• Memory clock speed
• 1600 MHz

• Memory form factor
• SO-DIMM

• Memory Installed
• 8 GB

• Memory Slot Support
• 16 GB

• Memory slots
• 2x SO-DIMM

• Network

• 4G WiMAX
• No

• Bluetooth
• Yes

• Bluetooth version
• 4.0

• Data network
• Not supported

• Ethernet LAN
• Yes

• Ethernet LAN data rates
• 10,100,1000 Mbit/s

• Wi-Fi
• Yes

• Wi-Fi standards
• 802.11b, 802.11g, Wi-Fi 4 (802.11n)

• Operational conditions

• Operating relative humidity (H-H)
• 20 - 85%

• Operating temperature (T-T)
• 5 - 35 °C

• Storage temperature (T-T)
• -15 - 60 °C

• Other features

• AC adapter included
• Yes

• Maximum internal memory (64-bit)
• 16 GB

• Packaging content

• Cables included
• AC

• Manual
• Yes

• Quick start guide
• Yes

• Warranty card
• Yes

• Ports & interfaces

• CardBus PCMCIA slot type
• No

• Charging port type
• DC-in jack

• Docking connector
• No

• DVI port
• No

• Ethernet LAN (RJ-45) ports
• 1

• ExpressCard slot
• Yes

• HDMI ports
• 1

• Headphone connectivity
• 3.5 mm

• Headphone outputs
• 1

• Microphone connectivity
• 3.5 mm

• Microphone in
• Yes

• S/PDIF out port
• No

• SmartCard slot
• No

• USB 2.0 ports quantity
• 3

• USB Sleep-and-Charge
• Yes

• USB Sleep-and-Charge ports
• 1

• VGA (D-Sub) ports quantity
• 1

• Power

• AC adapter frequency
• 50 - 60 Hz

• AC adapter input voltage
• 100 - 240 V

• AC adapter output current
• 3.25 A

• AC adapter output voltage
• 20 V

• AC adapter power
• 65 W

• Processor

• Bus type
• DMI

• CPU multiplier (bus/core ratio)
• 24

• ECC supported by processor
• No

• FSB Parity
• No

• Maximum number of PCI Express lanes
• 16

• Motherboard chipset
• Intel® HM75 Express

• Number of Cores
• 2

• PCI Express configurations
• 1x16, 2x8, 1x8+2x4

• PCI Express slots version
• 2.0

• Processor
• 2020M

• Processor cache
• 2 MB

• Processor cache type
• Smart Cache

• Processor codename
• Ivy Bridge

• Processor family
• Intel® Pentium®

• Processor frequency
• 2.4 GHz

• Processor lithography
• 22 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor series
• Intel Pentium 2000 series for Mobile

• Processor socket
• PGA988

• Processor threads
• 2

• Stepping
• L1

• System bus rate
• 5 GT/s

• Thermal Design Power (TDP)
• 35 W

• Tjunction
• 90 °C

• Processor special features

• Conflict-Free processor
• Yes

• CPU configuration (max)
• 1

• Embedded options available
• No

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Graphics & IMC lithography
• 22 nm

• Idle States
• Yes

• Integrated 4G WiMAX
• No

• Intel 64
• Yes

• Intel Clear Video Technology
• No

• Intel Demand Based Switching
• No

• Intel Dual Display Capable Technology
• Yes

• Intel Enhanced Halt State
• Yes

• Intel Fast Memory Access
• Yes

• Intel FDI Technology
• Yes

• Intel Flex Memory Access
• Yes

• Intel Rapid Storage Technology
• No

• Intel Smart Connect Technology
• No

• Intel Trusted Execution Technology
• No

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• No

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• No

• Intel® Anti-Theft Technology (Intel® AT)
• No

• Intel® Clear Video HD Technology (Intel® CVT HD)
• No

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• No

• Intel® Hyper Threading Technology (Intel® HT Technology)
• No

• Intel® Insider™
• No

• Intel® InTru™ 3D Technology
• No

• Intel® My WiFi Technology (Intel® MWT)
• Yes

• Intel® Quick Sync Video Technology
• No

• Intel® Rapid Start Technology
• No

• Intel® Smart Cache
• Yes

• Intel® Smart Response Technology
• No

• Intel® Turbo Boost Technology
• No

• Intel® Wireless Display (Intel® WiDi)
• No

• Processor ARK ID
• 71142

• Processor code
• SR0U1

• Processor package size
• 37.5 x 37.5 (rPGA988B)

• Supported instruction sets
• SSE4.1, SSE4.2

• Thermal Monitoring Technologies
• Yes

• Security

• Cable lock slot
• Yes

• Password protection type
• BIOS, HDD, Supervisor, User

• Software

• Drivers included
• Yes

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 8.1

• Storage

• Card reader integrated
• Yes

• Compatible memory cards
• SD, SDHC

• HDD capacity
• 750 GB

• HDD interface
• SATA

• HDD size
• 2.5"

• HDD speed
• 5400 RPM

• Number of HDDs installed
• 1

• Optical drive type
• DVD Super Multi

• Storage Capacity
• 750 GB

• Storage type
• HDD

• Weight & dimensions

• Depth
• 252 mm

• Height
• 36.5 mm

• Weight
• 2.5 kg

• Width
• 378 mm
