• Audio

• Audio chip
• Realtek ALC3266

• Audio system
• MaxxAudio Pro

• Built-in microphone
• Yes

• Number of built-in speakers
• 2

• Speaker power
• 2 W

• Speakers manufacturer
• Waves

• Battery

• Battery capacity
• 97 Wh

• Battery charge indicator
• Yes

• Battery charge status button
• Yes

• Battery life (max)
• 19.5 h

• Battery recharge time
• 4 h

• Battery technology
• Lithium-Ion (Li-Ion)

• Battery voltage
• 11.4 V

• Number of battery cells
• 6

• Camera

• Front camera
• Yes

• Front camera HD type
• HD

• Front camera resolution
• 1280 x 720 pixels

• Front camera resolution (numeric)
• 0.9 MP

• Front camera signal format
• 720p

• Video capturing speed
• 30 fps

• Design

• Form factor
• Clamshell

• Housing material
• Aluminium, Carbon fibre

• Market positioning
• Business

• Product colour
• Black, Silver

• Product type
• Laptop

• Display

• Display bezel technology
• InfinityEdge

• Display brightness
• 350 cd/m²

• Dual-screen
• No

• HD type
• Full HD

• LED backlight
• Yes

• Native aspect ratio
• 16:9

• Panel type
• IPS

• Pixel pitch
• 0.18 x 0.18 mm

• Screen Resolution
• 1920 x 1080 pixels

• Screen Size
• 39.6 cm (15.6")

• Touchscreen
• No

• Filters

• Machinecategory
• Notebook

• Graphics

• CUDA
• Yes

• CUDA cores
• 640

• Discrete graphics card
• Yes

• Discrete graphics card memory
• 4 GB

• Discrete graphics card model
• NVIDIA® GeForce® GTX 1050

• Discrete graphics memory type
• GDDR5

• Maximum on-board graphics card memory
• 64 GB

• Number of discrete graphics cards installed
• 1

• NVIDIA G-SYNC
• Yes

• NVIDIA GameWorks VR
• No

• On-board graphics card
• Yes

• On-board graphics card base frequency
• 350 MHz

• On-board graphics card DirectX version
• 12.0

• On-board graphics card dynamic frequency (max)
• 1100 MHz

• On-board graphics card ID
• 0x591B

• On-board graphics card model
• Intel® HD Graphics 630

• On-board graphics card OpenGL version
• 4.4

• Keyboard

• Full-size keyboard
• Yes

• Keyboard backlit
• Yes

• Numeric keypad
• No

• Palmrest keyboards supported
• Belgian, Czech, French, German, International EER+North Sea, Italian, Portuguese, Slovakian, Spanish, Swiss, Turkish

• Pointing device
• Touchpad

• Windows keys
• Yes

• Logistics data

• Intermodal container (20ft) loading note
• 78pc/PLT*10PLT+52pc*10plt

• Layers per pallet
• 3 pc(s)

• Maximum number of stacking cartons
• 6 pc(s)

• Pallet gross height
• 114.2 cm

• Pallet gross length
• 120 cm

• Pallet gross weight
• 296.1 kg

• Pallet gross width
• 100 cm

• Pallet volume weight
• 288 kg

• Pallets per intermodal container (20ft)
• 20 pc(s)

• Products per intermodal container (20ft)
• 1300 pc(s)

• Products per intermodal container (40ft, HC)
• 3276 pc(s)

• Products per pallet
• 78 pc(s)

• Products per pallet layer
• 26 pc(s)

• Shipping (inner) case gross weight
• 3.69 kg

• Shipping (inner) case height
• 33.4 cm

• Shipping (inner) case length
• 49.1 cm

• Shipping (inner) case volume weight
• 2.46 kg

• Shipping (inner) case width
• 9 cm

• Memory

• Internal memory type
• DDR4-SDRAM

• Memory clock speed
• 2400 MHz

• Memory form factor
• SO-DIMM

• Memory Installed
• 16 GB

• Memory Slot Support
• 32 GB

• Memory slots
• 2x SO-DIMM

• Network

• Antenna type
• 2x2

• Bluetooth
• Yes

• Bluetooth version
• 4.1

• Ethernet LAN
• No

• Top Wi-Fi standard
• Wi-Fi 5 (802.11ac)

• Wi-Fi
• Yes

• Wi-Fi standards
• Wi-Fi 5 (802.11ac)

• WLAN controller model
• Killer Wireless-AC 1535

• Operational conditions

• Non-operating altitude
• -15.2 - 10668 m

• Non-operating shock
• 160 G

• Non-operating vibration
• 1.3 G

• Operating altitude
• -15.2 - 3048 m

• Operating relative humidity (H-H)
• 10 - 90%

• Operating shock
• 110 G

• Operating temperature (T-T)
• 0 - 35 °C

• Operating vibration
• 0.66 G

• Storage relative humidity (H-H)
• 0 - 95%

• Storage temperature (T-T)
• -40 - 65 °C

• Other features

• AC adapter included
• Yes

• EPEAT rating
• 93.4%

• Maximum internal memory (64-bit)
• 32 GB

• Memory upgrade note
• Additional memory sold separately

• USB Power Delivery revision
• 2.0

• Wide-angle lens front camera
• Yes

• Packaging content

• Manual
• Yes

• Power cord included
• Yes

• Quick start guide
• Yes

• Warranty card
• Yes

• Packaging data

• Package material
• Bamboo molded pulp, Corrugated cardboard, Low-density polyethylene (LDPE), Polypropylene (PP)

• Package weight
• 3.2 kg

• Ports & interfaces

• Charging port type
• DC-in jack

• Combo headphone/mic port
• Yes

• Docking connector
• No

• DVI port
• No

• HDMI ports
• 1

• HDMI version
• 1.4

• Number of Thunderbolt 3 ports with PowerShare support
• 1

• Number of USB ports with PowerShare support
• 2

• PowerShare
• Yes

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 2

• USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
• 1

• USB Power Delivery
• Yes

• USB Sleep-and-Charge
• Yes

• USB Sleep-and-Charge ports
• 2

• Power

• AC adapter frequency
• 50 - 60 Hz

• AC adapter input voltage
• 100 - 240 V

• AC adapter output current
• 6.67 A

• AC adapter output voltage
• 19.5 V

• AC adapter power
• 130 W

• Processor

• Bus type
• DMI3

• Configurable TDP-down
• 35 W

• ECC supported by processor
• No

• Maximum number of PCI Express lanes
• 16

• Motherboard chipset
• Intel® HM175

• Number of Cores
• 4

• PCI Express configurations
• 1x16, 1x8, 2x4, 2x8

• PCI Express slots version
• 3.0

• Processor
• i7-7700HQ

• Processor boost frequency
• 3.8 GHz

• Processor cache
• 6 MB

• Processor cache type
• Smart Cache

• Processor codename
• Kaby Lake

• Processor family
• Intel® Core™ i7

• Processor frequency
• 2.8 GHz

• Processor generation
• 7th gen Intel® Core™ i7

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor series
• Intel Core i7-7700 Mobile Series

• Processor threads
• 8

• System bus rate
• 8 GT/s

• Thermal Design Power (TDP)
• 45 W

• Tjunction
• 100 °C

• Processor special features

• Conflict-Free processor
• Yes

• CPU configuration (max)
• 1

• Embedded options available
• No

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Graphics & IMC lithography
• 14 nm

• Idle States
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• Yes

• Intel Enhanced Halt State
• Yes

• Intel Flex Memory Access
• Yes

• Intel Identity Protection Technology version
• 1.00

• Intel Secure Key Technology version
• 1.00

• Intel Small Business Advantage (SBA) version
• 1.00

• Intel Smart Response Technology version
• 1.00

• Intel Software Guard Extensions (Intel SGX)
• Yes

• Intel Stable Image Platform Program (SIPP)
• No

• Intel Stable Image Platform Program (SIPP) version
• 0.00

• Intel Trusted Execution Technology
• No

• Intel TSX-NI
• No

• Intel TSX-NI version
• 0.00

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Clear Video HD Technology (Intel® CVT HD)
• Yes

• Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• Yes

• Intel® InTru™ 3D Technology
• Yes

• Intel® My WiFi Technology (Intel® MWT)
• Yes

• Intel® OS Guard
• Yes

• Intel® Quick Sync Video Technology
• Yes

• Intel® Secure Key
• Yes

• Intel® Smart Cache
• Yes

• Intel® Smart Response Technology
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Intel® Wireless Display (Intel® WiDi)
• Yes

• Processor ARK ID
• 97185

• Processor package size
• 42 x 28 mm

• Supported instruction sets
• AVX 2.0, SSE4.1, SSE4.2

• Thermal Monitoring Technologies
• Yes

• Thunderbolt™ 3 Technology
• Yes

• Recycling data

• Bamboo molded pulp content per package
• 68 g

• Corrugated cardboard content per box for accessories
• 39 g

• Corrugated cardboard content per package
• 736 g

• Corrugated cardboard content per shipping (inner) case
• 697 g

• Low-density polyethylene (LDPE) content per package
• 52 g

• Polypropylene (PP) content per package
• 5 g

• Security

• Cable lock slot
• Yes

• Cable lock slot type
• Kensington

• Fingerprint reader
• No

• Password protection
• Yes

• Password protection type
• BIOS, Supervisor, User

• Trusted Platform Module (TPM)
• Yes

• Software

• Bundled software
• Financial Tracker & Retail Information Additional Software (Win10)

• Drivers included
• Yes

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 10 Home

• Operating system language
• German, Dutch, English, French, Italian

• Pre-installed software
• Skype, Microsoft Edge, Dropbox

• Trial software
• McAfee LiveSafe (30 days Trial), Microsoft Office (30 days Trial - Excludes Office License)

• Storage

• Card reader integrated
• Yes

• Compatible memory cards
• SD, SDHC, SDXC

• Number of SSDs installed
• 1

• Optical drive type
• No

• SSD capacity
• 512 GB

• SSD form factor
• M.2

• SSD interface
• PCI Express 3.0

• Storage Capacity
• 512 GB

• Storage type
• SSD

• Sustainability

• Sustainability certificates
• EPEAT Gold, ENERGY STAR

• Weight & dimensions

• Depth
• 235 mm

• Height (front)
• 1.1 cm

• Height (rear)
• 1.7 cm

• Weight
• 1.8 kg

• Width
• 357 mm
