• Audio

• Audio chip
• Realtek ALC3287

• Audio system
• Dolby Audio Premium

• Built-in microphone
• Yes

• Number of built-in speakers
• 2

• Number of microphones
• 2

• Speaker power
• 2 W

• Battery

• Battery capacity
• 57 Wh

• Battery life (max)
• 15 h

• Battery technology
• Lithium-Ion (Li-Ion)

• Fast charging
• Yes

• Bullet points

• Point
• 15.6" Full HD 1920 x 1080 IPS
  16GB DDR4-SDRAM & 512GB SSD
  3 Year Onsite Support
  Intel Core i7-8665U (1.9GHz)
  Windows 10 Pro 64-bit

• Camera

• Front camera
• Yes

• Front camera HD type
• HD

• Front camera resolution
• 1280 x 720 pixels

• Front camera signal format
• 720p

• Infrared (IR) camera
• Yes

• Privacy camera
• Yes

• Privacy type
• Privacy shutter

• Design

• Form factor
• Clamshell

• Housing material
• Polyamide, Polyphenylene sulfide (PPS)

• Intel® vPro™ Platform Eligibility
• Yes

• Product colour
• Black

• Product type
• Mobile workstation

• Display

• Contrast ratio (typical)
• 700:1

• DCI-P3 coverage
• 45%

• Display brightness
• 250 cd/m²

• Dual-screen
• No

• HD type
• Full HD

• LED backlight
• Yes

• Native aspect ratio
• 16:9

• Panel type
• IPS

• Screen Resolution
• 1920 x 1080 pixels

• Screen Size
• 39.6 cm (15.6")

• Touchscreen
• No

• Filters

• Machinecategory
• Mobile workstation

• Graphics

• Discrete graphics card
• Yes

• Discrete graphics card memory
• 2 GB

• Discrete graphics card model
• NVIDIA Quadro P520

• Discrete graphics memory type
• GDDR5

• Maximum on-board graphics card memory
• 32 GB

• Number of discrete graphics cards installed
• 1

• On-board graphics card
• Yes

• On-board graphics card base frequency
• 300 MHz

• On-board graphics card DirectX version
• 12.0

• On-board graphics card dynamic frequency (max)
• 1150 MHz

• On-board graphics card family
• Intel® UHD Graphics

• On-board graphics card ID
• 0x3EA0

• On-board graphics card model
• Intel® UHD Graphics 620

• On-board graphics card OpenGL version
• 4.5

• Keyboard

• Full-size keyboard
• Yes

• Keyboard backlit
• Yes

• Keyboard language
• UK English

• Keyboard layout
• QWERTY

• Numeric keypad
• Yes

• Pointing device
• ThinkPad UltraNav

• Spill-resistant keyboard
• Yes

• Windows keys
• Yes

• Memory

• Internal memory type
• DDR4-SDRAM

• Memory clock speed
• 2400 MHz

• Memory form factor
• On-board + SO-DIMM

• Memory Installed
• 16 GB

• Memory Slot Support
• 48 GB

• Memory slots
• 1x SO-DIMM

• Network

• Antenna type
• 2x2

• Bluetooth
• Yes

• Bluetooth version
• 5.0

• Ethernet LAN
• Yes

• Ethernet LAN data rates
• 10,100,1000 Mbit/s

• Mobile network connection
• No

• Top Wi-Fi standard
• Wi-Fi 5 (802.11ac)

• Wi-Fi
• Yes

• Wi-Fi standards
• 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)

• WLAN controller model
• Intel Dual Band Wireless-AC 9560

• Other features

• 3D
• No

• AC adapter included
• Yes

• Packaging content

• Manual
• Yes

• Ports & interfaces

• Charging port type
• USB Type-C

• Combo headphone/mic port
• Yes

• Docking connector
• Yes

• Ethernet LAN (RJ-45) ports
• 1

• HDMI ports
• 1

• HDMI version
• 1.4b

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 2

• USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
• 1

• USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
• 1

• USB Power Delivery
• Yes

• USB Sleep-and-Charge
• Yes

• USB Sleep-and-Charge ports
• 1

• USB Type-C DisplayPort Alternate Mode
• Yes

• Power

• AC adapter power
• 65 W

• Processor

• Configurable TDP-down
• 10 W

• Configurable TDP-down frequency
• 0.8 GHz

• Configurable TDP-up
• 25 W

• Configurable TDP-up frequency
• 2.1 GHz

• Maximum number of PCI Express lanes
• 16

• Number of Cores
• 4

• PCI Express configurations
• 1x4, 2x2, 1x2+2x1, 4x1

• PCI Express slots version
• 3.0

• Processor
• i7-8665U

• Processor boost frequency
• 4.8 GHz

• Processor cache
• 8 MB

• Processor cache type
• Smart Cache

• Processor codename
• Whiskey Lake

• Processor family
• Intel® Core™ i7

• Processor frequency
• 1.9 GHz

• Processor generation
• 8th gen Intel® Core™ i7

• Processor lithography
• 14 nm

• Processor manufacturer
• Intel

• Processor operating modes
• 64-bit

• Processor socket
• BGA 1528

• Processor threads
• 8

• System bus rate
• 4 GT/s

• Thermal Design Power (TDP)
• 15 W

• Tjunction
• 100 °C

• Processor special features

• CPU configuration (max)
• 1

• Embedded options available
• No

• Enhanced Intel SpeedStep Technology
• Yes

• Execute Disable Bit
• Yes

• Idle States
• Yes

• Intel 64
• Yes

• Intel Clear Video Technology
• Yes

• Intel Flex Memory Access
• Yes

• Intel Software Guard Extensions (Intel SGX)
• Yes

• Intel Stable Image Platform Program (SIPP)
• Yes

• Intel Trusted Execution Technology
• Yes

• Intel TSX-NI
• Yes

• Intel Virtualization Technology (VT-x)
• Yes

• Intel Virtualization Technology for Directed I/O (VT-d)
• Yes

• Intel VT-x with Extended Page Tables (EPT)
• Yes

• Intel® AES New Instructions (Intel® AES-NI)
• Yes

• Intel® Clear Video HD Technology (Intel® CVT HD)
• Yes

• Intel® Hyper Threading Technology (Intel® HT Technology)
• Yes

• Intel® Identity Protection Technology (Intel® IPT)
• Yes

• Intel® My WiFi Technology (Intel® MWT)
• Yes

• Intel® OS Guard
• Yes

• Intel® Quick Sync Video Technology
• Yes

• Intel® Secure Key
• Yes

• Intel® Smart Response Technology
• Yes

• Intel® Turbo Boost Technology
• 2.0

• Processor ARK ID
• 193563

• Processor package size
• 46x24 mm

• Supported instruction sets
• SSE4.1, SSE4.2, AVX 2.0

• Thermal Monitoring Technologies
• Yes

• Security

• Cable lock slot
• Yes

• Fingerprint reader
• Yes

• Password protection
• Yes

• Password protection type
• HDD, Power on, Supervisor

• Trusted Platform Module (TPM)
• Yes

• Software

• Operating system architecture
• 64-bit

• Operating system installed
• Windows 10 Pro

• Operating system language
• English

• Storage

• Card reader integrated
• Yes

• Compatible memory cards
• MicroSD (TransFlash)

• Flash drive interface
• PCI Express

• Number of SSDs installed
• 1

• NVMe
• Yes

• Optical drive type
• No

• SSD capacity
• 512 GB

• SSD form factor
• M.2

• SSD interface
• NVMe

• Storage Capacity
• 512 GB

• Storage type
• SSD

• Total SSDs capacity
• 512 GB

• Sustainability

• Sustainability certificates
• RoHS, EPEAT Silver, ENERGY STAR

• Weight & dimensions

• Depth
• 248 mm

• Height
• 19.1 mm

• Weight
• 1.75 kg

• Width
• 365.8 mm
