• Audio

• Audio chip
• Realtek ALC3287

• Audio system
• Dolby Audio

• Built-in microphone
• Yes

• Number of built-in speakers
• 2

• Number of microphones
• 2

• Speaker power
• 2 W

• Battery

• Battery capacity
• 75 Wh

• Battery technology
• Lithium-Ion (Li-Ion)

• Fast charging
• Yes

• Number of battery cells
• 3

• Bullet points

• Point
• 16" WUXGA 1920 x 1200 IPS, NVIDIA RTX PRO 500 Blackwell (6GB GDDR7)
  16GB (5600MHz) DDR5-SDRAM (1 x 16) & 512GB SSD
  Intel Core Ultra 7 255H (24MB Cache)
  Windows 11 Pro

• Camera

• Front camera
• Yes

• Front camera resolution (numeric)
• 5 MP

• Infrared (IR) camera
• Yes

• Privacy camera
• Yes

• Privacy type
• Privacy shutter

• Certificates

• Certification
• TCO Certified, generation 10 MIL-STD-810H Eyesafe Certified 2.0 TÜV Rheinland Low Blue Light

• Compliance certificates
• RoHS

• Design

• Display back cover material
• Aluminium

• Form factor
• Clamshell

• Housing material
• Aluminium

• Product colour
• Black

• Product type
• Mobile workstation

• Display

• Anti-glare screen
• Yes

• Colour gamut
• 45%

• Contrast ratio (typical)
• 1200:1

• Display brightness
• 400 cd/m²

• HD type
• WUXGA

• LED backlight
• Yes

• Max Refresh Rate
• 60 Hz

• Native aspect ratio
• 16:10

• Panel type
• IPS

• RGB colour space
• NTSC

• Screen Resolution
• 1920 x 1200 pixels

• Screen Size
• 40.6 cm (16")

• Touchscreen
• No

• Graphics

• Discrete GPU manufacturer
• NVIDIA

• Discrete graphics card
• Yes

• Discrete graphics card memory
• 6 GB

• Discrete graphics card model
• NVIDIA RTX PRO 500 Blackwell

• Discrete graphics memory type
• GDDR7

• On-board GPU manufacturer
• Intel

• On-board graphics card
• Yes

• On-board graphics card family
• Intel Arc Graphics

• On-board graphics card model
• Intel Arc 140T

• Keyboard

• Copilot key
• Yes

• Keyboard backlit
• Yes

• Keyboard language
• UK English

• Numeric keypad
• Yes

• Pointing device
• ThinkPad UltraNav

• Spill-resistant keyboard
• Yes

• Memory

• Internal memory type
• DDR5-SDRAM

• Memory channels
• Dual-channel

• Memory clock speed
• 5600 MHz

• Memory form factor
• SO-DIMM

• Memory Installed
• 16 GB

• Memory layout (slots x size)
• 1 x 16 GB

• Memory Slot Support
• 96 GB

• Memory slots
• 2x SO-DIMM

• Non-ECC
• Yes

• Network

• Antenna type
• 2x2

• Bluetooth
• Yes

• Bluetooth version
• 5.4

• Ethernet LAN
• Yes

• Ethernet LAN data rates
• 100,1000 Mbit/s

• Mobile network connection
• No

• Near Field Communication (NFC)
• No

• Top Wi-Fi standard
• Wi-Fi 7 (802.11be)

• Wi-Fi standards
• Wi-Fi 7 (802.11be)

• WLAN controller manufacturer
• Intel

• WLAN controller model
• Intel Wi-Fi 7 BE201

• WWAN
• Not installed

• Neural processor unit (NPU)

• AI software frameworks supported by NPU
• DirectML, OpenVINO, Windows ML, ONNX RT, WebNN

• GPU performance up to
• 74 TOPs

• Neural processor unit (NPU)
• Intel AI Boost

• NPU performance up to
• 13 TOPs

• Sparsity support
• Yes

• Total processor performance up to
• 96 TOPs

• Windows Studio effects support
• Yes

• Operational conditions

• Maximum shipping altitude
• 3048 m

• Operating relative humidity (H-H)
• 8 - 95%

• Operating temperature (T-T)
• 5 - 35 °C

• Storage relative humidity (H-H)
• 5 - 95%

• Storage temperature (T-T)
• 5 - 43 °C

• Packaging content

• AC adapter included
• Yes

• Performance

• Motherboard chipset
• Intel SoC

• Ports & interfaces

• Combo headphone/mic port
• Yes

• Ethernet LAN (RJ-45) ports
• 1

• HDMI ports
• 1

• HDMI version
• 2.1

• Intel® Thunderbolt 4
• Yes

• Thunderbolt 4 ports quantity
• 2

• USB 2.0 ports quantity
• 0

• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
• 2

• USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
• 0

• USB Sleep-and-Charge
• Yes

• USB Sleep-and-Charge ports
• 1

• USB Type-C DisplayPort Alternate Mode
• Yes

• Power

• AC adapter frequency
• 50/60 Hz

• AC adapter input voltage
• 100 - 240 V

• AC adapter power
• 100 W

• USB Power Delivery (USB PD)
• Yes

• USB Type-C charging port
• Yes

• Processor

• Efficient cores
• 8

• Efficient-core base frequency
• 1.5 GHz

• Efficient-core Max Turbo Frequency
• 4.4 GHz

• Low Power Efficient-core Base Frequency
• 700 MHz

• Low Power Efficient-core Max Turbo Frequency
• 2.5 GHz

• Low Power Efficient-cores
• 2

• Maximum turbo power
• 115 W

• Number of Cores
• 16

• Performance cores
• 6

• Performance-core base frequency
• 2 GHz

• Performance-core Max Turbo Frequency
• 5.1 GHz

• Processor
• 255H

• Processor base power
• 28 W

• Processor boost frequency
• 5.1 GHz

• Processor cache
• 24 MB

• Processor cache type
• Smart Cache

• Processor family
• Intel Core Ultra 7

• Processor generation
• Intel Core Ultra (Series 2)

• Processor manufacturer
• Intel

• Processor socket
• BGA 2049

• Processor threads
• 16

• Security

• Cable lock slot
• Yes

• Cable lock slot type
• Kensington

• Fingerprint reader
• Yes

• Password protection
• Yes

• Password protection type
• BIOS, Power on, Supervisor

• Smart card reader
• Yes

• Trusted Platform Module (TPM)
• Yes

• Trusted Platform Module (TPM) version
• 2.0

• Windows Hello
• Yes

• Software

• Bundled software
• Lenovo AI Now

• Operating system installed
• Windows 11 Pro

• Operating system language
• ENG-UK, US English

• Storage

• Card reader integrated
• No

• M.2 SSD size
• 2280 (22 x 80 mm)

• Number of SSDs installed
• 1

• NVMe
• Yes

• Optical drive type
• No

• SSD capacity
• 512 GB

• SSD form factor
• M.2

• SSD interface
• PCI Express 5.0

• Storage Capacity
• 512 GB

• Storage type
• SSD

• Total SSDs capacity
• 512 GB

• Sustainability

• Sustainability certificates
• ENERGY STAR, EPEAT Gold

• Weight & dimensions

• Depth
• 248.6 mm

• Height (front)
• 1.26 cm

• Height (rear)
• 1.82 cm

• Weight
• 1.82 kg

• Width
• 361.5 mm
