AddOn Networks ADD-LC-LC-10M9SMFPA InfiniBand/fibre optic cable 10 m OFNR Yellow

Roll over image to zoom inClick to Open expanded view

AddOn Networks ADD-LC-LC-10M9SMFPA InfiniBand/fibre optic cable 10 m OFNR Yellow

Name: AddOn Networks ADD-LC-LC-10M9SMFPA InfiniBand/fibre optic cable 10 m OFNR Yellow
Brand: AddOn Networks
SKU: ADD-LC-LC-10M9SMFPA

SKU: ADD-LC-LC-10M9SMFPA

Log In to View Pricing

ETA 2 days

AddOn Networks ADD-LC-LC-10M9SMFPA, 10 m, OFNR, OS2, LC, LC

ETA 2 days

Add to compare

Product Properties

Manufacturer
AddOn Networks

Warranty
Limited Lifetime

SKU
ADD-LC-LC-10M9SMFPA

EAN
0821456064763

Certificates

Certification
CE, ISO/IEC 11801, TIA/EIA-568-C.3, TIA-604-5 (FOCIS-5), TIA/EIA-568-C.1, GR-409-CORE, ICEA S-83-596

Compliance certificates
RoHS

Features

Cable length
10 m

Cable type
OFNR

Cladding diameter
125 µm

Compressive strength
10

Connector 1
LC

Connector 1 gender
Male

Connector 2
LC

Connector 2 gender
Male

Connector material
Ceramic

Connector polish type
UPC

Core diameter
9 µm

Data transfer rate
10 Gbit/s

Ethernet interface type
10 Gigabit Ethernet, 40 Gigabit Ethernet, 100 Gigabit Ethernet

Fiber mode structure
Single-mode

Fibre optic type
OS2

Full duplex
Yes

Insertion loss
0.35 dB

Jacket material
Low smoke zero halogen (LSZH)

Product colour
Yellow

Return loss
30 dB

Wavelengths supported
1310,1550 nm

Operational conditions

Operating temperature (T-T)
0 - 60 °C

Storage temperature (T-T)
-10 - 70 °C

Packaging content

Quantity per pack
1 pc(s)

Sustainability

Doesn't contain
Halogen

Weight & dimensions

Cable diameter
1.6 mm

Description

AddOn Networks ADD-LC-LC-10M9SMFPA. Cable length: 10 m, Cable type: OFNR, Fibre optic type: OS2, Connector 1: LC, Connector 2: LC, Core diameter: 9 µm, Full duplex

OFNR OS2
10 m
LC Male
LC Male
Connector polish type: UPC
Jacket material: Low smoke zero halogen (LSZH)
10 Gbit/s
Full duplex Single-mode
Yellow
