LevelOne 34-Port Fast Ethernet PoE Switch, 802.3at/af PoE, 32 PoE Outputs, 2 x Gigabit RJ45, 380W

Roll over image to zoom inClick to Open expanded view

LevelOne 34-Port Fast Ethernet PoE Switch, 802.3at/af PoE, 32 PoE Outputs, 2 x Gigabit RJ45, 380W

Name: LevelOne 34-Port Fast Ethernet PoE Switch, 802.3at/af PoE, 32 PoE Outputs, 2 x Gigabit RJ45, 380W
Brand: LevelOne
SKU: FGP-3400W380

SKU: FGP-3400W380

ETA 7 days

LevelOne 34-Port Fast Ethernet PoE Switch, 802.3at/af PoE, 32 PoE Outputs, 2 x Gigabit RJ45, 380W, Unmanaged, Fast Ethernet (10/100), Full duplex, Power over Ethernet (PoE), Rack mounting

ETA 7 days

hypertec

Datasheets (Download)

Add to compare

Product Properties

Manufacturer
LevelOne

Warranty
1 Year

SKU
FGP-3400W380

EAN
4015867203255

Bullet points

Certificates

Certification
FCC Class A, CE

Data transmission

Jumbo frames
16000

Jumbo frames support
Yes

MAC address table
32000 entries

Packet buffer memory
8 MB

Packet forwarding rate (1 Gbps)
1488000 pps

Packet forwarding rate (10 Mbps)
14880 pps

Packet forwarding rate (100 Mbps)
148800 pps

Switching capacity
10.4 Gbit/s

Design

LED indicators
LAN, PoE, Power, Uplink

On/off switch
Yes

Product colour
Black

Rack mounting
Yes

Logistics data

Country of origin
Taiwan

Harmonized System (HS) code
85176990

Master (outer) case gross weight
17.8 kg

Master (outer) case height
280 mm

Master (outer) case length
555 mm

Master (outer) case width
510 mm

Products per master (outer) case
5 pc(s)

Management features

Switch type
Unmanaged

Network

Cable types supported
Cat3, Cat4, Cat5, Cat5e, Cat6, Cat7

Copper ethernet cabling technology
10BASE-T, 100BASE-TX, 1000BASE-T

Flow control support
Yes

Full duplex
Yes

Networking standards
IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x

Operational conditions

Operating relative humidity (H-H)
10 - 90%

Operating temperature (T-T)
0 - 40 °C

Storage relative humidity (H-H)
10 - 90%

Storage temperature (T-T)
-20 - 70 °C

Packaging content

Cables included
AC

Quick start guide
Yes

Rack mount kit
Yes

Packaging data

Package depth
534 mm

Package height
95 mm

Package type
Box

Package weight
3.3 kg

Package width
255 mm

Rubber feet
Yes

Performance

Mean time between failures (MTBF)
74000 h

Ports & interfaces

Fast Ethernet (copper) ports quantity
32

Gigabit Ethernet (copper) ports quantity
2

Installed SFP modules quantity
0

Installed SFP+ modules quantity
0

Switch Number of Ports
32

Switch Port Speed
Fast Ethernet (10/100)

Power

AC input frequency
50 - 60 Hz

AC input voltage
100 - 240 V

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Yes

Power over Ethernet (PoE) power per port
30 W

Power over Ethernet plus (PoE+) ports quantity
32

Total Power over Ethernet (PoE) budget
380 W

Weight & dimensions

Depth
480 mm

Height
45 mm

Weight
2.8 kg

Width
195 mm

Description

LevelOne 34-Port Fast Ethernet PoE Switch, 802.3at/af PoE, 32 PoE Outputs, 2 x Gigabit RJ45, 380W. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 32. Full duplex. MAC address table: 32000 entries, Switching capacity: 10.4 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x. Power over Ethernet (PoE). Rack mounting

Unmanaged
Basic switching RJ-45 Ethernet ports quantity: 32
Cat3, Cat4, Cat5, Cat5e, Cat6, Cat7 10BASE-T, 100BASE-TX, 1000BASE-T
MAC address table: 32000 entries Switching capacity: 10.4 Gbit/s
Rack mounting
Power over Ethernet (PoE)
PoE on/off control per port by dip switches
IEEE 802.3af/at PoE PSE with 30W power budget
IEEE 802.3af PoE compliant to simplify deployment and installation
IEEE 802.3x Flow Control protects against lost packets for reliable data transmission
19-inch rackmount kit included

pdf

Datasheets (Download)
